RFID 125KHz Dual Decoding ASK/FSK Read Module

Introduction

The 125KHz proximity reading module equipped with the ASK / FSK dual decoding circuits to read the both EM & HC contactless cards or tags into ABA, Wiegand & UART formats. In this version, we output the Wiegand 26 bits or UART or ABA signal by external jumper selection. Additionally, we supported various module versions to answer different requirements, please refer to our products catalog.

Features

•125KHz proximity dual decoding technologies reading for EM, TEMIC, HC cards at the same mode.

•Embedded with internal antenna or external bigger antenna at the same model.

•Epoxy potted for weather resistant with reliable quality.

•Compact size with high performance.

•Ease system design for access control, fingerprint, mobile handheld device etc.

Specification

Applications

Ordering information

PIEH-FWAS-14H22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 26 bits, ABA(14D), UART(Hexadecimal, 10 digits, 9,600 bps), with internal antenna.

PXEH-FWAS-14H22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 26 bits, ABA(14D), UART(Hexadecimal, 10 digits, 9,600 bps), without internal antenna.

PIEH-FWAS-24H22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 34 bits, ABA(14D), UART(Hexadecimal, 10 digits, 9,600 bps), with internal antenna.

PXEH-FWAS-24H22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 34 bits, ABA(14D), UART(Hexadecimal, 10 digits, 9,600 bps), without internal antenna.

PIEH-FWAS-14D22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 26 bits, ABA(14D), UART(Decimalism, 10 digits, 9,600 bps), with internal antenna.

PXEH-FWAS-14D22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 26 bits, ABA(14D), UART(Decimalism, 10 digits, 9,600 bps), without internal antenna.

PIEH-FWAS-24D22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 34 bits, ABA(14D), UART(Decimalism, 10 digits, 9,600 bps), with internal antenna.

PXEH-FWAS-24D22:

125KHz EM(ASK) & HC(FSK) dual decoding reading module with format of Wiegand 34 bits, ABA(14D), UART(Decimalism, 10 digits, 9,600 bps), without internal antenna.

We reserve the right to change the specification without priornotice or obligation!
