Home > Instruments & Meters > Meter for Liquid & Gas > Flow Meter > Household Ultrasonic Heat Meter

Household Ultrasonic Heat Meter

Household Ultrasonic Heat Meter photo-1
Household Ultrasonic Heat Meter photo-2
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Gaoxiang Meter
Model Number:
LXS-MJL-13-40E
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name Gaoxiang Meter
Model Number LXS-MJL-13-40E

                                                                 Household ultrasonic heat meter

Application and Warnings





The installation requirements of the heat meter



Before installation, check the pipelines in the cleansing system thoroughly and remove silk, hemp ,sand ,gravel and any other masses to avoid any flow hindrance.



n  The flow meter should be installed in horizontal level, with the display window facing upward.



n  The water flows in the direction accordance with the arrow mark



n  The diameter of the front and the back pipes should fit the flow meter



n  10DN straight pipeline and 5DN straight line should be saved (DN is what we call the diameter of the heat meter)



n  Must use the gasket and connecting pipeline specially designed and manufactured by our company.



n  The sewage filter and the valve should be fixed at both ends of the flow meter for the convenience of filth removing, maintaining and replacing.



n  After the installation ,seal between the connecting bolt of the capsule and the heat meter, between the temperature measuring ball valve and the platinum resistor.



n  Best water inflow and outflow pipeline options for easy fixing



The installation of temperature sensor



One temperature sensor with red tag is to be installed inside the heat measuring meter, the other sensor with blue tag is to be built inside the temperature measuring ball valve.



The lead wire of the temperature sensor is not allowed to be lengthen, shorten or changed casually.



heat meter Performance



Household mechanical heat meter bears the features of high accuracy, steady operation, long using life, no subjecting to inferior water and low maintaining cost .It can be widely used in concentrated or regional heat supply system or separate household measuring in central air condition system
