Help CenterUntrasonic Heating Meter
Related Products
Specifications
LXRS15-40 Untrasonic water meter is an untrasonic flow sensor that measure the velocity of water by using the principle of untra
SPECIFICATION:
GXRS15-40 Ultrasonic water meter is an ultrasonic flow sensor that measures the velocity of water.
Ultrasonic Water Meter is an ultrasonic flow sensor that measures the velocity of water by using the principle of ultrasound.All measurements, references, readings and calculations are controlled by a microprocessor in the calculator top. The accumulated water consumption is displayed with eight significant digits and measuring unit.
Ultrasonic water meters measure the difference of the transit time of ultrasonic pulses propagating in and against flow direction; The meter is available to be integrated in a wireless network, you can select radio, wireless M-bus and PLC.
FEATURES:
1,Low pressure drops
2,No metering of air
3, Leading to long lasting metrology
4,Pinpoint measuring accuracy
5, Mounting in any installation position
6,Insensitive against lime & sand
STANDARD COMPLIANCE:
EN1434-2007, ISO 4064
COMMUNICATION:
Permanent optical port communication With standard M-bus protocol Meter open to a series of possible communication option boards
METROLOGICAL CLASS: Class B or Class C
PRESSURE LOSS: <25kPa/qp
MAXIMUM OPERATION PRESSURE: 1.6 Mpa
ALARM:
1,when the residual water is lower,the meter will send out the alarm,
2,when the temperature sensor open circuit of short circuit,the valve will closed automatically and send out the alarm.
3,low voltage or attack damage,valves closed automatically and send out alarm.
BATTERY:3.6VDC,D-cell lithium
TEMPERATURE OF MEDIUM
4oC - 95oC
WATER TEMPERATURE DIFFERENTIATION
1oC - 105oC
INSTALLATION METHOD
Horizontal or Vertical
PROTECTION CLASS
IP68
PRESSURE STAGE
PN16
TEMPERATURE SENSOR
PT1000 platinum resistor
DISPLAY
8 digits+LCD
Type |
Norminal Caliber (mm) |
Maximum Flowrate |
Permanent Flowrate |
Minimum Flowrate |
Installation Size |
||
DN |
qs (m3/h) |
qp (m3/h) |
qi (m3/h) |
Meter Length L (mm) |
Total Length L1 (mm) |
Hight H (mm) |
|
DN20 |
20 |
5 |
2.5 |
0.05 |
130 |
235 |
110 |
DN25 |
25 |
7 |
3.5 |
0.07 |
160 |
280 |
110 |
DN32 |
32 |
12.0 |
6.0 |
0.07 |
180 |
300 |
110 |
Pls contact us, if you have any needs!
