Home > Products > Warehouse rack(Heavy duty) > heavy duty warehouse storage racking system
heavy duty warehouse storage racking system
- 50000 Set / Sets per Month
- Shanghai
- T/T
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | AMJ | Model Number: | AMJ-NEW04 |
Type: | Pallet Rack | Scale: | Heavy Duty | Capacity: | capacity weight:1tons to 5tons |
Product Description
Specifications
Racking system:*Strong, robust and reliable
*Easily adjusted
*Easily adapted to suit available space
*CE and BV approved
Racking system:
Product Name | Racking system |
Brand Name | AMJ |
Features | 1) Beams adjustable in 75mm pitch interval |
2) Customization available as per specific requirements | |
3) Easy up botless | |
4) Optimized storage options within minimum space | |
5) Comprehensive range of decking and accessory options | |
6) Safety standards well met. | |
Loading Capacity/Level | 150-3000kgs UDL per level |
Dimensions | Height: As your request |
Depth: As your request | |
Length: As your request | |
Other customized dimensions available |
Detailed specifications:
1. Upright:
70*90*2.0mm
60*80*2.0mm
40*80*2.0mm
30*50*2.0mm
C-type Upright | ||||
Model | Depth(mm) | Width(mm) | ||
U-1 | 70 | 90 | ||
U-2 | 60 | 80 | ||
U-3 | 40 | 80 | ||
U-4 | 30 | 50 |
2. Beam: 50*100*1.5mm,50*100*2.0mm
50*120*1.5mm,50*120*2.0mm
50*140*1.5mm,50*140*2.0mm
50*160*1.5mm,50*160*2.0mm
50*80*(1.5-2.0)mm
40*60*(1.0-1.5)mm
30*50*(1.0-1.5)mm
Step Beam | Box Beam | |||||||||
Model | Depth(mm) | Width(mm) | Model | Depth(mm) | Width(mm) | |||||
B-1P | 50 | 80 | B-1R | 50 | 80 | |||||
B-2P | 50 | 100 | B-2R | 50 | 100 | |||||
B-3P | 50 | 110 | B-3R | 50 | 110 | |||||
B-4P | 50 | 120 | B-4R | 50 | 120 | |||||
B-5P | 50 | 140 | B-5R | 50 | 140 | |||||
B-6P | 40 | 60 | B-6R | 40 | 60 | |||||
B-7P | 30 | 50 | B-7R | 30 | 50 |
Mass Production:
Loading containers:
Some of our customers:
