heavy duty pallet rack

Specifications

Pallet rack:
*Strong, robust and reliable
*Easily adjusted
*Easily adapted to suit available space
*CE and BV approved

Pallet rack:



Product Name	Pallet Rack
Brand Name	AMJ
Features	1) Beams adjustable in 75mm pitch interval
	2) Customization available as per specific requirements
	3) Easy up botless
	4) Optimized storage options within minimum space
	5) Comprehensive range of decking and accessory options
	6) Safety standards well met.
Loading Capacity/Level	150-3000kgs UDL per level
Dimensions	Height: As your request
	Depth: As your request
	Length: As your request
	Other customized dimensions available



Detailed specifications:

1. Upright:

70*90*2.0mm

60*80*2.0mm

40*80*2.0mm

30*50*2.0mm

C-type Upright
		Model	Depth(mm)	Width(mm)
		U-1	70	90
		U-2	60	80
		U-3	40	80
		U-4	30	50



2. Beam: 50*100*1.5mm,50*100*2.0mm

                 50*120*1.5mm,50*120*2.0mm

                 50*140*1.5mm,50*140*2.0mm

                 50*160*1.5mm,50*160*2.0mm

                 50*80*(1.5-2.0)mm

                 40*60*(1.0-1.5)mm

                 30*50*(1.0-1.5)mm

Step Beam						Box Beam
		Model	Depth(mm)	Width(mm)				Model	Depth(mm)	Width(mm)
		B-1P	50	80				B-1R	50	80
		B-2P	50	100				B-2R	50	100
		B-3P	50	110				B-3R	50	110
		B-4P	50	120				B-4R	50	120
		B-5P	50	140				B-5R	50	140
		B-6P	40	60				B-6R	40	60
		B-7P	30	50				B-7R	30	50
