High Quality and High-Precision Aluminum Pneumatic Cylinder Tube with Best Price and Delivery on Time

Name: High Quality and High-Precision Aluminum Pneumatic Cylinder Tube with Best Price and Delivery on Time
Brand: FULLYWOW
Price: USD $2,500 - 3,200 / Ton

FOB Price

USD $2,500 - $3,200 / Ton

1 Ton(Min.Order)

Supply Ability 3000 Ton / Tons per Month
Port Shanghai or Ningbo
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Grade:	6000 Series	Shape:	Other, round/rectiangel/square/flat,T-slot,tee shape
Surface Treatment:	Other, Polish, Mill finish and anodize	Outer Diameter:	8mm~125mm	Length:	Customers Requested
Thickness:	above 0.5mm	Usage:	Industry	Hardness:	T3-T8
Alloy Or Not:	Is Alloy	Temper:	T3 - T8	Al (Min):	98.8%
Wall Thickness:	0.8MM----40MM	Model Number:	FLH-J0322	Brand Name:	FULLYWOW

Product Description

Product name: Aluminum Pneumatic Cylinder Tube

Our main products are Industrial Aluminum Profile, Aluminum Profile for Solar Panels, Aluminum Profile for Windows and Doors, Aluminum Pipes, Aluminum Tubes, Aluminum Windows, Aluminum Doors, Aluminum Solar Module Frame, etc.

Note:

If you need Aluminum Square Tubes or Round Tubes as following, please order directly with our model no., you will save mould cost.

Drawings of Square & Round Aluminum Pipes or Aluminum Tubes or Aluminum Tubing.

1.Specifications

Material	6063,6060,6061,6005
Temper	T4,T5,T6
Surface treatment	Mill Finish,Anodized,Eletropharesis,Powder Coated, Wooden Finish, Polish
Colour	Silver,Black,Red,Blue,or as required
Length	≤6m
Shape	Round,Square,T-slot,or as per the drawings and samples
Fabrication	cutting,drilling,punching,bending,etc
Wall thickness	≥0.5mm
Package	inner plastic paper interleaving each piece profile,outer fixed by plywood, or as per your requirements

2.Primary Technical Data of Aluminum Profile

1) Chemical composition

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Impurity	Al
6063	0.2-0.6	0.35	0.1	0.1	0.45-0.9	0.1	0.1	0.1	0.15	Rest
6061	0.4-0.8	0.70	0.15-0.4	0.15	0.8-1.2	0.04-0.35	0.25	0.15	0.15	Rest
6005	0.6-0.9	0.35	0.1	0.1	0.4-0.6	0.1	0.1	0.1	0.15	Rest

2) Mechanical property

Alloy	Temper	Tensile strength	Yield strength	Elongation
6061	T6	≥ 265Mpa	≥ 245Mpa	≥ 8%
6063	T5	≥ 160Mpa	≥ 110Mpa	≥ 8%
6063	T6	≥ 205Mpa	≥ 180Mpa	≥ 8%

3) Anodized

Grade	Anodizing thickness		Hole scaling quality of oxide layer
Grade	Average thickness	Local thickness	P. Cr acid-erosion weight less method
AA10	≥10um	≥8um	≤30 mg/d m²
AA15	≥15um	≥12um	≤30 mg/d m²

4) Powder coating & wooden-grained

Coating thickness	Coating impress rigidity	Adhesive force of coating layer
40-120um	Indentation hardness>80	0 grade

3. Energy Saving and Enviroment-Friendly Aluminum Profile:

Insulated/thermal-break profile with excellent energy-saving, heat resistance, sound insulation, and noise reduction. High strength, good resistance for wind pressure. Excellent mechanical property. Good sealing effect and water-proof. Strong toughness.

We can produce aluminum products upon clients' requests. Please send the drawings to us.

Packaging & Shipping

Generally aluminum profiles will be covered PE protective film on the surface, then soft plastic interleave profiles. Each or several aluminum profiles will be wraped into bundles. Or the packing will be made as you requested. Pictures of packing and pictures as following

Our Services

The FULLYWOW TEAM is ready to assist with any product needs or enquiries. We value our customers and welcome your thoughts and feedback.

Please send comments, questions and requests through alibaba or our personal contacts so they can be directed to the appropriate department.

About samples: For your designed alumimum profiles, we will produce and send samples to you to check before production.

Working time:8:00~17:00(GM+8) from Monday to Saturday, but anythings urgently you also can contact with us via personal contacts during our leisure time. We will try our best to offer you service in 24*7 hours.

Problems: Any quality, quantity problems are occured, response you will get in time not over more 24 hours after we recieve your complains. Problems will be solved in one week throught friendly negotiation.

Company Information

Zhejiang FULLYWOW ALUMINUM Co., Ltd. is a high-tech enterprise which develops and produces all kinds of environment-friendly aluminum alloy profiles.

The company is located in the north shore scenic of Hangzhou Bay - Yuantong Industry Zone, Haiyan, Zhejiang. It is near to Shanghai, distance 80km away only. And Haiyan is connected to Hang-Pu superhighway, Hu-Hang superhighway, Zha-Jiasu superhighway and Hangzhou Bay Cross-Sea Bridge, which takes the most convenient location for business

FULLYWOW Aluminum covers an area of more than 80000 square meters. It was registered with capital of 30million RMB and a total investment of 120million RMB in the first period. We mainly produce various kinds of environment-friendly Industrial Aluminum Profiles, Aluminum Solar Module Frames, Aluminum Windows and Doors, Aluminum Curtain Wall Profiles with injection-plastic and barrier strip. The capability of annual output is 500million RMB.

The company has two efficient and energy-saving melting furnaces with capability of 15tons, eight advanced technology extrusion production lines from Japanese Mitsubishi, three spraying production lines from Germany, one anodizing and electrophoresis production line from Italy, one dulling electrophoresis production line from Japan, two injection-plastic production lines, two barrier strip production lines and two sand-blasting production lines. There are two advanced technology domestic production lines which can carve and emboss 2D, 3D, 4D wood grain, and we won the national invention patent on the technology.
Our company has consistently adhered to the business purpose of "market-oriented, taking management as the basis, quality as the life and reputations as the fundament".

We always provide first-class products and first-class services to our customers. We sincerely look forward to your long-term cooperation on the basis of mutual benefits to establish a good business partnership. We would like to go hand in hand with you for development together.

FAQ

Q: Can you provide free samples?

A: Yes, free samples will be sent to you on freight at destination.

Q: Can I get your latest catalogue?
A: Yes, it will be sent to you in time.

Q: What is the MOQ?
A: 1 tons

Q: What are your payment terms?
A: We accept L/C, D/A, D/P, T/T, West Union,etc.

If you are interested in our products, please do not hesitate to contact with us via following information

Contact Us

Zhejiang Fullywow Aluminium Industry Co., Ltd.: Contact nameMicah Jiang; Phone86-573-86882161; AddressXinxing Village, Xitangqiao Town, Haiyan County
