Everbest precision polished high purity al2o3 ceramic tube
- 10000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Everbest | Model Number: | YJ00221 |
Theory: | Other, Ceramic tube | Structure: | Other | Usage: | Other, Connector |
Power: | Pneumatic | Standard or Nonstandard: | Nonstandard | Fuel: | Other |
Pressure: | High Pressure | Application: | Other |
Product Description
Specifications
1.Material:99% alumina ceramic2.High mechanical strength
3.Polishing surface,wear resistance
4,customised
Everbest precision polished high purity al2o3 ceramic tube
Feature
Al2o3 ceramic tube has the advantages of high wear-resisting,good corrosion resistance,high intensity , precision process,good smoothness,polishing surface and so on.It widely used in a variety of mechanical equipment.
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
Forming methods includes
1,Drying pressing
2,Isostatic pressing
3,Hot pressing casting
More about us.
Suzhou Everbest engineering ceramic Co.,LTD is specialized in designing and manufacturing structure cereamic products and related parts.which has more than 14 years experience in ceramic structures.
Our general ceramic parts include: ceramic tube, ceramic rod, ceramic plate, ceramic disc valve, ceramic wafer, ceramic seal, ceramic bearing bushing, ceramic valves, ceramic pump plunger, ceramic beam, ceramic roller, ceramic shaft, ceramic screw, ceramic sleeve, ceramic washer, ceramic lamp holder, ceramic insulator, ceramic nozzle, ceramic lining, ceramic guide, ceramic bushing, ceramic substrates, ceramic piston, ceramic ferrule etc.
Remarks
Shaped as customers' requirement and drawing.
