Home > Products > Ceramic sleeve/ring > Everbest High temperature alumina ceramic busing
Everbest High temperature alumina ceramic busing
- 8000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | Everbest | Type: | Insulating Ceramics |
| Material: | Alumina |
Product Description
Specifications
1.Precision dimension2.Mechanical seals good
3.Wear resistance
4,Shaped as your designing and requirement
Everbest High temperature alumina ceramic busing
Feature
Alumina ceramic bushing has the advantages of high wear-resisting,good corrosion resistance , high intensity , precision process, good smoothness, polishing surface and so on.It widely used in a variety of aquarium equipment.
Property
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
Forming methods includes
1, ceramic shaft for aquatic animals equipment filter pump
2, Ceramic plunger for high pressure cleaner.
3,Wearlessness,resistant acid-base and high intensity ceramic assembly apply to petroleum ,chemical and chemical industry.
4,Wearlesness, corrosion resistance, thermostable parts apply to precision machine.
Remarks
