Specifications
High temperature alumina ceramic lined pipe1.Material:99 Alumina
2.Abrasion resistance
3.Accurate slotted hole
4,Customised
High temperature alumina ceramic lined pipe
1.Feature
Alumina ceramic lined pipe with precision burnish and groove and has the advantages of high wear-resisting,good corrosion resistance , high intensity , precision process, good smoothness, polishing surface and so on.It widelly used in a variety of mechanical field.
2. Forming methods includes
1,Drying pressing
2,Isostatic pressing
3,Hot pressing casting
3.Properties of Alumina Al2O3
Alumina (Al2O3) is a hard, chemically resistant material and has the ability to withstand very high temperatures in aggressive environments. Innovacera offers Alumina with various purity levels, including 99.8% and 99.0%. The level of purity, grain size, and density required is dependent on the rigors of the application and the component configuration.
Items |
Unit |
95%Al2O3 |
99.5%Al2O3 |
Density |
g/cm3 |
3.7 |
3.9 |
Flexural Strength |
MPa |
313 |
340 |
Compressive Strength |
MPa |
3400 |
3600 |
Modulus of Elasticity |
GPa |
350 |
380 |
Impact Resistance |
MPa·m1/2 |
4 |
5.1 |
Weibull Modulus |
m |
10 |
10 |
Vickers Hardness |
HV0.5 |
1800 |
1900 |
Thermal Conductivity |
W/mk |
24 |
27 |
Highest Application Temperature |
°C |
1600 |
1750 |
Volume Resistivity at 20°C |
Ω.cm20 |
>1014 |
>1014 |
Dielertric strength |
KV/mm |
20 |
25 |
Thermal expansion |
X10-6/K |
5.0-8.3 |
5.4-8.3 |
4.More about us:
Suzhou Everbest engineering ceramic Co.,LTD is specialized in designing and manufacturing structure cereamic products and related parts.which has more than 14 years experience in ceramic structures.
Our general ceramic parts include: ceramic tube, ceramic rod, ceramic plate, ceramic disc valve, ceramic wafer, ceramic seal, ceramic bearing bushing, ceramic valves, ceramic pump plunger, ceramic beam, ceramic roller, ceramic shaft, ceramic screw, ceramic sleeve, ceramic washer, ceramic lamp holder, ceramic insulator, ceramic nozzle, ceramic lining, ceramic guide, ceramic bushing, ceramic substrates, ceramic piston, ceramic ferrule etc.
Remarks
Shaped as customers' requirment and drawing.If you are interested in our products, please don't hesitate to contact with us,we will reply to you at the first time and provide our the best price,the highest quality,the fastest delivery and the best professional service to you.
