tile forming machine Hydraulic Roofing Tiles Press Type TL-YWJ-100

Dimension L x W x H

  1,650 x 1,840 x 2,460   (mm)

Working Interval/Min.

   8-10   (times/min)

Main Power

7.5   (kw)

Working Table L x W

700 x 900   (mm)

Main Cylinder Max. Pressure

1000    (kn)

System Max. Pressure

20     (mpa)

Pushing Cylinder Stroke

570    (mm)

Main Cylinder Max. Stroke

440    (mm)

Working Table High from Ground

550    (mm)

Weight

≈ 4500     (kg)

Standard Set

Mechanical Jacks System: Four-pillar frame, mould forward & backward device with two-way and straight-line guider sliding and ball leading screw, main cylinder, pneumatic components, manipulator,fan etc. Electric Auto-Control System: Japanese MITSUBISHI PLC coding component, 100x40 liquid crystal display control panel, photo-electricity-ruler etc.

Features of Type TL-YWJ-100

 The Press type TL-YWJ-100 newly designed and made of leading technology by our team is for producing different kinds and styles of roofing tiles, like Spanish style, French style, Chinese style and Japanese style etc. and also different types of surfaces like polished type, knurling type and stone-grain type etc., through which, the high density and strength and characteristics of finished products are compressed under 100 tons pressure with TL mould series, The advanced features listed as simple-structured, easy-handling, and high-efficient ensure reliable of quality of finished roofing tiles, which smooth in surface, precise in dimensions and more individual in style. It performed efficiently, automatically as well as lower manual error when matched with the TL Roofing Tiles Manipulator Type TL-JXS-A that worked by negative force picking up the tiles on mould to next process after molding pressing process. It is the good choice among similar at home and abroad.
