Digital optical fiber 4 channel video converter
Video Optical transmitter receiver converted into a variety of coding equipment optical signal transmitted through the optical fiber medium between the one and multi-channel. The principle of video optical principle is to modulate the signal light, through fiber-optic video transmission.
| Video specification | Port | 4 | |||
| Video Interface | BNC | ||||
| Video In/Out put Impedance | 75Ω | ||||
| Video In/Out put Voltage | (typical)1.0Vp-p Max:1.5Vp-p | ||||
| Video Broad Band | 5-8MHZ | ||||
| Differential Gain | <1%(typical) | ||||
| Differential Phase | <0.6° | ||||
| SNR | >=68dB | ||||
| Field Gradient | <0.5% | ||||
| Data Characteristics | Physical connector | Phoenix contact(DATA) | |||
| Data connector | RS-485/422,RS232 | ||||
| Channels of data | forward and reverse path data multi-channels | ||||
| Interface port | Industrial standard interface port | ||||
| Environment Specification | Working Temperature | range from -30 to +75 | |||
| Storage Temperature | range from -40 to +85 | ||||
| Humidity | 0-95% | ||||
| Optical Budget | Fiber type | MM | SM | SM | SM |
| Budget | 20dB | 20dB | 22dB | 25dB | |
| Transmission Distance | 2KM | 20KM | 40KM | 60KM | |
| Other specification | Rated Voltage | AC220V/50HZ | |||
| Power supply | DC5V/1A | ||||
| Power | <5W | ||||
| Sampling rate | 15MHZ | ||||
| MTBF | >=10,000Hours | ||||
1.Monitoring
2.Surveillance in expressways
3.The custom
4.Transportation
5.Electronic police
6.Industrial automation
7.Power service
8.Banks
9.Water conservation projects, etc.
Our philosophy is to provide our clients with a wide choice of quality product and unprecedented services. We assure our clients of a mutually beneficial relationship as we look forward to developing a long term strategic partnership with your estimated organization.The mission of our company is “GREAT”: Greet all customers and make them fell welcomed; Respect cultural and other personal different; Evaluate and clarity customer’s expectations; Address and respond to customer’s needs; Thank and verify that needs have been met.
--Advantage we have:
A: Experienced fiber optic product supplier
B: professional technology term and sales department for your service.
C: Alibaba golden supplier, factory recognized by CE
D:All the question will be dealed within 24 hours.
--Benefit you get:
A: stable quality- coming from good material and technology
B: lower price: not cheapest but the lowest at the same quality
C: good service: satisfactory service before and after sale.
