Home > Products > fiber optic video tranceiver > 2Ch Video with 1Return Data Fiber SM 20km fiber video converter
2Ch Video with 1Return Data Fiber SM 20km fiber video converter
- 1000000000 Piece / Pieces per Month
- shenzhen
- Credit Card
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | HXT | Model Number: | HXT-VIDEOT |
Product Description
2Ch Video with 1Return Data Fiber SM 20km fiber video converter
Video Optical transmitter receiver converted into a variety of coding equipment optical signal transmitted through the optical fiber medium between the one and multi-channel. The principle of video optical principle is to modulate the signal light, through fiber-optic video transmission.
Video specification | Port | 2 | |||
Video Interface | BNC | ||||
Video In/Out put Impedance | 75Ω | ||||
Video In/Out put Voltage | (typical)1.0Vp-p Max:1.5Vp-p | ||||
Video Broad Band | 5-8MHZ | ||||
Differential Gain | <1%(typical) | ||||
Differential Phase | <0.6° | ||||
SNR | >=68dB | ||||
Field Gradient | <0.5% | ||||
Data Characteristics | Physical connector | Phoenix contact(DATA) | |||
Data connector | RS-485/422,RS232 | ||||
Channels of data | forward and reverse path data multi-channels | ||||
Interface port | Industrial standard interface port | ||||
Environment Specification | Working Temperature | range from -30 to +75 | |||
Storage Temperature | range from -40 to +85 | ||||
Humidity | 0-95% | ||||
Optical Budget | Fiber type | MM | SM | SM | SM |
Budget | 20dB | 20dB | 22dB | 25dB | |
Transmission Distance | 2KM | 20KM | 40KM | 60KM | |
Other specification | Rated Voltage | AC220V/50HZ | |||
Power supply | DC5V/1A | ||||
Power | <5W | ||||
Sampling rate | 15MHZ | ||||
MTBF | >=10,000Hours |
1.Monitoring
2.Surveillance in expressways
3.The custom
4.Transportation
5.Electronic police
6.Industrial automation
7.Power service
8.Banks
9.Water conservation projects, etc.
Our philosophy is to provide our clients with a wide choice of quality product and unprecedented services. We assure our clients of a mutually beneficial relationship as we look forward to developing a long term strategic partnership with your estimated organization.The mission of our company is “GREAT”: Greet all customers and make them fell welcomed; Respect cultural and other personal different; Evaluate and clarity customer’s expectations; Address and respond to customer’s needs; Thank and verify that needs have been met.
--Advantage we have:
A: Experienced fiber optic product supplier
B: professional technology term and sales department for your service.
C: Alibaba golden supplier, factory recognized by CE
D:All the question will be dealed within 24 hours.
--Benefit you get:
A: stable quality- coming from good material and technology
B: lower price: not cheapest but the lowest at the same quality
C: good service: satisfactory service before and after sale.
