10 100 1000M 20KM Single Mode fiber optic to coaxial converter
- 10000 Piece / Pieces per Month
- shenzhen
- Credit Card
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | HXT, coaxial converter | Model Number: | HT-3002-20KM A/B |
Product Description
10 100 1000M 20KM Single Mode fiber optic to coaxial converter
10/100 / 1000M auto-adaptive Ethernet fiber optical transceiver, using the latest design, high-performance chips, high-quality optical transceiver module, stable function and excellent quality, adaptability, and common network equipment can normally connection. For telecommunications, broadcasting, broadband networks that require high-speed, high data traffic and high-performance, high-reliability Ethernet environment.
Specification
1.OEM or ODM is available.
2.RJ-45 and 1*SC
3.10M/100M/1000Mbps
Band Width | RJ 45 Port:10/100/1000Mbps | Optical Port: 155Mbps |
Standard Protocol | IEEE802.3 10 Base-T standard | |
IEEE802.3u 10/100Base-TX/FX standard | ||
IEEE 802.3X standard. | ||
Connectors | UTP RJ-45 | SC/ST/FC Fiber connector |
Operation Mode | Full /Half duplex mode | |
Power Supply | External 5V DC 1A | |
Internal AC220V/50Hz | ||
Power Consumption | ≤5W | |
Environmental Parameters | Work Temperature | -30°C~+65°C |
Storage Temperature | -40°C~85°C | |
Humidity | 5%~90% | |
TP Cable | Cat5 UTP cable | |
Fiber | Single-mode: 8.3/125, 8.7/125, 9/125 or 10/125μm |
Transfer fiber:
- multi-mode: 50/125, 62.5/125 or 100/140μm
- single mode: 8.3/125, 8.7/125,
- 9/125 or 10/125μm
- Dimensions:
- External power supply: 26mmx 70mm x 95mm
- Built-in power supply: 30mm x 110mm x 140mm
Cautions:
1. This product is suitable for indoor application.
2. Put on the dust cover of fiber interface when not used.
3. It is forbidden to stare at the TX fiber-transfer end with naked eyes.
4. Single optical fiber transceiver must be used in pair (See the attachment description in delivery).
Interface
1. RJ-45 interface
The transmission media adopts CAT5 twisted-pair with typical length of 100 meter. It features the function of automatically identifying the through line and cross wire
2. Fiber interface
SC/ST fiber interface is of duplex mode type, including two interfaces, namely TX and RX. When the two sets of optical transceiver are interfaced or connected to switch with fiber interface, the fiber is in cross connection, namely "TX-RX", "RX-TX" (direct butting for single optical fiber).
Application
1,Optical fiber communications systems;
2,Optical fiber access network;
3,Optical fiber CATV.
4,Optical fiber test equipments;
5,Optical fiber data communications;
6,LAN
