Help CenterAluminum Chassis 2 Seats Electric Golf Cart
US$ 5,300 - 5,500
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Seats:
1 - 2
Fuel Type:
Electric
Battery Voltage:
48V
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 High Quality 20'' Elelctric Folding Bike With EN15194 ApprovedNegotiableMOQ: 20 Pieces -
2015 New Design Mountain Electric BikeUS$ 490 - 495MOQ: 20 Pieces
-
Graceful E-bike/Lady Electric BikeNegotiableMOQ: 20 Pieces
-
Foldable E-bike/Folding Electric Bike/ Popular Fold Electric BicycleNegotiableMOQ: 20 Pieces
-
Foldable E-bike/Folding Electric Bike/ Popular Fold Electric BicycleNegotiableMOQ: 20 Pieces
Seats
1 - 2
Fuel Type
Electric
Battery Voltage
48V
Certification
EEC
Aluminum chassis 2 seats electric golf cart / electric car
| Frame | Ladder-style steel box beam fully weather proofed | ||
| Body & Finish | Thermoplastic,Color impregnated, pre-mix mould injection, Scratch proof | ||
| Color Options | Standard white/black/yellow/blue /champagne/as requested | ||
| Dimension | |||
| Overall Length | 2380mm | ||
| Overall Width | 1210mm | ||
| Overall Height (top of steering wheel) | 885mm | ||
| Overall Height (top of sun canopy) | 1710mm | ||
| Wheel Base | 1630mm | ||
| Front Wheel Track | 870mm | ||
| Rear Wheel Track | 985mm | ||
| Ground Clearance | 110mm | ||
| Power | |||
| Power Source | 48 volt DC L/A Battery through Curtis Controller to ADC Motor | ||
| Motor Type | ADC motor | ||
| Horsepower (kw) | 3KW | ||
| Batteries (brand/qty/type) | Trojan 6pcs* 8v 150ah rechargeable L/A | ||
| Key or Pedal Start | Ignition Key - Throttle Peddle Start | ||
| Battery Charger (Spec/Safety e.g: UL, CSA) | 48v 25ah, UL | ||
| Speed Controller (brand/spec) | US.Curtis Instruments Model 1268-5402, 48V275A | ||
| Accelerator (brand/spec) | Curtis Instruments 5Kohm | ||
| Gear Selection | N/A | ||
| Rear Axle Ratio | 12.49:1 | ||
| Performance | |||
| Seating Capacity (persons) | 2 | ||
| Dry Weight (w/o batteries) | 310kg | ||
| Curb Weight | 480kg | ||
| Vehicle Load Capacity | 300kg | ||
| Ground Speed (level ground) | 24 K/P/H (15 MPH ) | ||
| Braking Distance | ≤13ft (4m) | ||
| Climbing Slope (°) | up to 30 | ||
| Turning Radius | 9.8ft (3m) | ||
| Steering & Suspension | |||
| Steering | Self centreing rack and pinion | ||
| Front Suspension | Eliptical Transverse Spring 45×8 spring steel,hydraulic shock absorbers | ||
| Rear Suspension | Eliptical Spring 45×10 spring steel | ||
| Service Brake (type) | Rear Drum Brakes | ||
| Parking Brake (type) | Dual Operation Auto Release Brake Pedal to Rear Drums | ||
| Tires (brand/spec/ply rated) | US.Carlise Cross Ply 4 Ply 18×8.5/8 | ||
