600V pv Charger/solar Charger/pv Device Power Supply

Name: 600V pv Charger/solar Charger/pv Device Power Supply
Brand: TonHe
SKU: 104737809
Availability: InStock

US$ 900 - 1,100 MOQ: 1 Unit

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

TonHe

Model Number:

TH600D20NZ-600

Shijiazhuang Tonhe Electronics Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin as required

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name TonHe

Model Number TH600D20NZ-600

Output Power Other, 12KW

Output Type Other, DC

Input Voltage Other, 420-600

Output Voltage 450-600

Output Current 20A

Specifications

1.multiple protections
2.output voltage 600VDC
nnect with solar panel to power pv device

Mode Item			TH600D20NZ-600
Output current(A)			20
Power(KW)			12
Weight(kg)			19
Cooling method			Natural cooling

Output adjustment range(VDC)		minimum	450
		Typical value	540
		maximum	600
Over voltage protection			640±20VDC
Input voltage range(VAC)		minimum	420
		Typical value	540
		maximum	665
Stability precision of voltage			±0.5%
Stability precision of current			±1%
Power factor			≥0.94
Efficiency			≥95%
Maximum noise(dB)			50
Storage temperature(°C)	minimum		-40
	Typical value		25
	maximum		60
Working temperature(°C)	minimum		-10
	Typical value		25
	maximum		40
Parallel instability			±5%
Start up time(s)			3~8
Ripple coefficient			≤0.5%
Over current protection			When output current over point value, it will stable output. The output current will not increase.
Output shot circuit protection			When short circuit the module will automatic protect itself. When the trouble is over ,the module recovery to work.
