Single Punch Tablet Press TDP
US$ 780 - 980
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
MINHUA
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
MINHUA
Model Number
TDP series
Type
Single Punch
Production Capacity
5000pcs per hour
Max. Pressure(KN)
10KN
Max. Tablet Thickness(mm)
6mm
Max. Tablet Diameter(mm)
12mm
Voltage
220
Power(W)
370
Weight
70KGS
Dimension(L*W*H)
530x340x570
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.single punch tablet press2.Design for mini factory or lab .
3.tablet diameter 6-12mm
This machine is used for tabletting different kinds of granular raw materials into round tablet. It is applicable to trial manufacturing in Lab or batch produce in small amount different kinds of tablet, sugar piece, calcium tablet and tablet of abnormal shape. It features a small desktop type press for motive and continual sheeting .It can also be hand-operated. Only one pair of punching die can be erected on this press .Both filling depth of material and thickness of tablet are adjustable.
Max. Pressure |
10Kn |
Max. Dia of Tablet |
12mm |
Max. Depth of Fill |
11mm |
Max. Thickness of Tablet |
6mm |
Production Capacity |
6000pc/h |
Power |
370W.1400r/min 380V 50Hz |
Overall Size |
530*340*570mm |
Net Weight |
60kg |
