Help CenterRotary Tablet Press Zpw-23
Related Products
Specifications
1.rotary tablet press2.max20-25mm
3.max thickness 11mm
4.Cover GMP
Specification:
This machine is a double-press type. continuous automatic tablet press for pressing granular raw materials into tablets. It is mainly used in pharmaceutical industry and also the chemical, food, electronic industries
The outside part of the machine is fully-enclosed, The material of the cover and the inside face is stainless steel. The turret face is specially disposed keeping the lustrous of the face and prevent the cross pollution, meeting the G.M.P requirement.
It has transparent windows so that press condition can be observed clearly and the window can be opened.
Cleaning and maintenance is easier.
The lay-out of all the controllers and the operate parts is reasonable.
The speed adjustment of the driver is controlled by the frequency conversion device.
All the drive devices are located inside the machine so keep the machine clean.
The hydraulic system can assure the stable of the system.
A overload protection unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs, the machine stops automatically.
This machine also has electronic magic driver and other safety protection device which can be adjusted and operated when running.
The punches and dies are also applicable to Model ZP19 ZP33.
Technical Parameter:
Stations (unit) |
23 sets |
Thickness of the die (mm) |
28mm |
Maximum compression (Kn) |
80 Kn |
The diameter of the circle of the central pitch of uppe lower punches on the turret (mm) |
320 mm |
Max. Diameter of tablet to be produced (mm) |
20 mm |
Rotary speed of thi turret (rpm) |
10-40 rpm |
Max. Filling depth (mm) |
22mm |
Capacity of the tablets (max ten thousand tablets/hour) |
55000 pcs/hour |
Max. Thickness of tablet (mm) |
11mm |
Area to occrpy (mm2) |
930×950mm |
Diameter of the upper/lower shank (mm) |
32mm |
Height of the machine (mm) |
1850mm |
Length of the upper shank (mm) |
175mm |
motor power (kw) |
4Kw |
Length of the lower shank (mm) |
183mm |
Net weight of the machine (kg) |
1500KGS |
Diameter of the die (mm) |
36mm |
|
|
