Specifications
DZH-100 Model multi-function Automatic Boxing MachineUse&Features
Machinery drive, variable frequency speed regulating, protection of automatic stop when the machine is over loading, control with PLC process, automatic checking of Aiming at the medical former and the explaining book''''s page-lack. Automatic waiting when the machine hasn''''t medical former. Having the equipments of products'''' count and intelligent failure''''s display.
the machine is used to take Ai-plastic medical former(including the medical formers which are full of ai-foil),plastic bottle (vitreous bottle )to fill in the paper-boxes automatically, including the explaining books'''' pucker(1-4 fold),paper-boxes'''' forming and using, codes'''' printing and the two sides of paper-boxes'''' sealing are also automatic .it can be also linked to produce with ai-plastic blister packing machine, bottle-filling lines and three dimension transparent film packing machine, etc.
Technical Parameters
running speed:3090box/min
size range of cardboard box
≥65*35*12mm
≤125*78*65mm
special machine:≤160*60*65mm
size of unfolded explaining book:70~210*80~300mm
size of folded explaining book:70~210*20~40mm
quality of operation manual:50~80g/m2
total power:0.75Kw
power:three phrase four wire 380V 50Hz
air-compressed:0.6~0.7MPa
air-compressor:0.12~0.16m3/min
overall dimensions:1300*1400*1560mm
weight:900Kg
