3 Phase 10kva voltage regulator price
SVC Single-phase high accuracy full automatic AC voltage stabilizers is made of regulator,servo motor,automatic control circuit and so in,When the voltage of the network is not
steady or the load varies,the automatic sampling control circuit makes a signal to drive the servomotor to adjust the postion of the carbon brush of the regulator so as to have
the output voltage regulated to the rating and to obtain the steady state.This machine has advantages of small volume,light weigh,undistorted waveform,high efficiency,reliabli
performance,and time-delay,over-voltage,etc,the series of stabilizers driven,of general type,the indeel boltage stabilized sources which can be widely applied to any occasions
requring power to assure the normal operation of yourpower driven equipment.
Features
(1) The AC voltage regulator is equipped with bypass system
(2) Compensated voltage technology is adopted
(3) Wide input voltage range
(4) Over voltage protection
(5) The voltage regulator has output voltage three phase auto-balance function
(6) SVC voltage regulators are widely used in electric power supply systems.
Technical Parameters
Power range: 1KVA-200KVA (Single phase)
Input voltage: single phase 220V±20% (176-264V), optional 220V±30% (154-286V) or larger range
Output voltage: single phase 220V±3%
Power range: 1KVA-2500KVA(three phase)
Input voltage: 3 phase 380V±20% (304-456V), optional 380V±30% (266-494V) or larger range
Output voltage: 3 phase 380V±3%
Custom made products in special input & output voltage is available, like 3 phase 220v, 400v, 415v, etc
Working frequency: 50Hz/60Hz; Response time: ≤1s; Efficiency: ≥98%
Waveform distortion: Do not produce additional waveform distortion
Protection function: overload, over current, over voltage, under voltage, short circuit, etc
Pictures
Application for dry type power transformer
More other products for your reference
More other products
Testing before delivery
Certificates
1. Pre sale service
a. make technical solution
b. send quotation, technical data sheet and drawing
c. make manufacturing plan, testing plan,and shipping plan
2. In sale service
a. supervise the manufacturing schedule totally in accordance with the plan
b, send photos to customer during every manufacturing process(hold point)
c. inform the customer one week before testinng.
d. book hotel and ticket for customer if they will come do FAT.
3. After sale service
a. installation and commissioning
b. training the workers
b. quick response within 12 hours any time
About HSLEC
1.Founded in 1992,Huashenglong Electrical Equipment Co.,Ltd.(HSLEC)is a mamufactuer of dry type
transformer and dry type reactor,located in Qinhuangdao,a beautiful coastal city of China.
2.We are able to research,develop,and produce many types of dry type transformer and dry type reactor,
high and low voltage transformers ,air core reactor,line reactor and so on.
Workshop
International Market
1.During the past 18 years, we have continued to upgrade and improve our equipment and our quality control system.
2.Now,HSLEC is a top ranked manufature in China's electrical equipment industry, and our power transformer,
current-limiting reactor,etc.,are exporeted to America,India,Thailand,Turkey,Georgia,and Sigapore,among others.
Customer visit
1.Q: Are you manufacturer or trading company?
A: Manufacturer
2.Q: What is your minimum order quantity?
A: 1 set.
3.Q: What is your delivery time ?
A: Depend on the type of transformer.
4.Q: What is your payment term?
A: 30% advance by T/T , 70% before delivery by T/T or L/C
or we can discuss about it.
5. Q: What kind of supporting documentation you can provide normally
A: Quotation,outline drawing,manufacturing plan, quality control plan
testing plan, financial report, type test report(KEMA, CESI),reference list,etc
