ISBE PISTON KIT 4955337 5255257

ISBE PISTON KIT 4955337 5255257 thumbnail-1
ISBE PISTON KIT 4955337 5255257 thumbnail-2
ISBE PISTON KIT 4955337 5255257 photo-1
ISBE PISTON KIT 4955337 5255257 photo-2
US$ 96 - 100 MOQ: 2 Sets
Key Specifications
Get Latest Price
Type:
Other, Piston, Engine piston kit
Size:
Standard Size
Car Make:
ISBE ISDE
Contact Supplier Request Quote Chat Now
Guangzhou TPK Diesel Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Piston, Engine piston kit
Size Standard Size
Car Make ISBE ISDE
OE NO. 4955337 5255257
Place of Origin Hunan, China
Brand Name TPK
Model Number ISBE ISDE ISB6.7
Warranty 12 Months
        ISBE  PISTON KIT 4955337 5255257
Product Description



Specifications For ISDE ISBE  Piston



Commodity:       Engine Piston
Model:       ISBE ISDE PISTON
Part No:        3907156  3802100
Vehicle
Cylinder dia:        107.0mm
Piston Pin Size:        47.0 mm* 90.0mm
Length:        103.2 mm
Remarks:        Alfin





Features of   ISBE ISDE Engine  Piston Kit



1:  AL109 piston skirt



2:  Top Quality, 1 year warranty



3:  Fast Delivery & Good packing(harden cartons and plywood)



4:  One-step service





Reference Pictures of   ISBE ISDE Engine  Piston Kit





 ISBE PISTON KIT 4955337 5255257ISBE PISTON KIT 4955337 5255257ISBE PISTON KIT 4955337 5255257ISBE PISTON KIT 4955337 5255257ISBE PISTON KIT 4955337 5255257













Packaging & Shipping



 ISBE PISTON KIT 4955337 5255257





Shipping



(1): By sea

(2): By air

(3): By express (DHL, FEDEX, TNT, EMS... )



Packing:



(1): TPK packing or nuetral packing

(2): according to your requirments







Our Services



Payment



(1): TT (30 %  in Advanced, 70 % before Shipment)
(2): Western Union
(3): Cash



Warranty



All our parts warranty 1 years, If problems from our parts itself, we will take all responsibilty on the spare parts and service.



If the troubles come from human factors, should take responsible for it.





Company Information





        Guangzhou TPK Diesel Parts Co.,Ltd, Build in 1996, is a professional  manufacturer on Diesel Piston, Piston ring, Cylinder Liner, Head Gasket & Overhaul Gasket Kit. TPK has been cooperating with OEM factory in China for several years, running business mainly in imported diesel engines . All products in TPK have passed the national quality supervision on combustion engines and obtained certificates from ISO9002.



Till now, TPK has four storehouses in Guangzhou, occupying an area of over 5,000 square meters. The number of employees in TPK reaches up to 100, among which include 20 sales personnel in China, 15 sales personnel outside China, 10 QC personnel. TPK products command a ready market in Europe, Middle East, South America, North America, and Southeast Asia and are well received.



With the principles of international brand, good quality, shared resources, and serving the world, TPK endeavors to provide perfect accessories replacement solutions for customers. TPK is ready to cooperte with you to reach a win-win future.





FAQ




Q:   Do you have any other engine parts?



A:   yes, we have more than 10 kinds of engine repair parts like the followings:



1: Cylinder block, cylinder head, crankshaft, camshaft, connecting rod.
2: Liner Kits. Piston kits, piston ring set, cylinder liner (sleeve), Pin bush.
3: Full / Overhaul gasket kit, head gasket,Oil Seal.
4: Engine bearing, Main bearing, con rod bearing,Camshaft Bearing,thrust washer
5: Engine valve, valve seat, valve guide.
6: Oil Pump, water pump,
7: Starter, alternator
9: Oil cooler, radiator
10: Turbocharger



Q: Do you have Some Other excavator engine models?



A:  yes, for CMS, we have the following models





C_U_M_M_I_N_S:



(1): 4BT,4BT3.9,4BTA,6BT,6BT5.9,6BTA,6BTA5.9,
(2): 6CT,6CTA,6CTAA,6CT8.3,6CTA8.3,6CTAA8.3
(3): 6L,L375,NH220,N14,NTA14,L10,LT10,
(4): NT855,NTA855,NTC,K19,KTA19,KTAA19,K38,KTA38,KTAA38
(5): ISBE, ISB3.9,ISB5.9, ISB6.7,ISCE,ISDE,ISDE107,
(6): M11,ISM,ISM11,QSM, ISF2.8,ISF3.8
(7): ISL,ISLE,ISL340,ISL375,L375,T375,ISLE375,
(8): QSB,QSB6.7,QSC,QSL,ISX,QSX,ISX15,QSX15





Q: Do you have Some Online service?



A:  yes, we have Whatspp, Wechat, Skype, YAHOO, QQ...





ENGINE KITS



122-1370 Seal valve stem 12 Intake, Yellow, Top hat style [3955393, 5086861AA]
Intake and Exhaust ISB6 (exc North Am) esn 21561274 Up; Intake all others
140-3033 Valve guide 12 Intake, 0.2780 ID, 0.5015 OD, 1.937 length; dualflange on guide, seal boss length
0.334
140-3080 Valve guide 12 Intake, 0.2775 ID, 0.4395 OD, 1.937 length; dualflange on guide, seal boss length
0.334, optional OD
140-3034 Valve guide 12 Exhaust, 0.2780 ID, 0.5015 OD, 2.020 length; dualflange on guide, seal boss length
0.334
140-3081 Valve guide 12 Exhaust, 0.2775 ID, 0.4395 OD, 2.020 length; dualflange on guide, seal boss length
0.334, optional OD
SB1375E-1 Valve insert 12 Intake, 1.100 ID, 1.3750 OD, 0.2270 Depth, OEM replacement (availalbe in .010 O/S)
SB1375E-2N Valve insert 2 Exhaust, 1.100 ID, 1.375 OD, 0.2270 Depth, OEM replacement (availalbe in .010 O/S)
[3942299]
3927063-EP Bolt cylinder head 26 M12 x 1.75-130 [3927063]
3164057-F Gauge head bolt 1 used to check the cylinder head bolt lengthfor stretching beyond the point of reuse
[replaces 3825140]
CRANKSHAFT
171621 Crankshaft 1 [3968164]
171623 Crankshaft 1 [2830477]
Industrial
CONNECTING ROD
3971212RX Connecting rod 6 Remanufactured, fracture split (Canonly be mixed with rod 3954658) [3971212
replaces 3954658; 3971211, 3954657]
2007-2009
171633 Connecting rod 6 New assembly, fracture split, singledimple cap, smooth side [4898808, 4891176,
4891177]
4943979-B Connecting rod 6 New assembly, fracture split, three dimple cap, bump or bulge side [4943979, 4943978]
4891179-F Bolt connecting rod 12 Used with fracture split rods
FUEL / INJECTOR
0986-435-518-090- Injector 6 Remanufactured, Bosch [5253220,4981076, 4940095, 68027067AA, R8002011AB;
0 445 120 193, 0445-120-193]
ISB: Dodge Ram pickup: 2007.5-2010
0986-435-519-090- Injector 6 Remanufactured, Bosch [5253221, 4981077, 4940096, 3970987; 6700201AB,
R8002012AB; 0 445 120 204, 0445-120-204]
ISB: Dodge Ram Cab-Chassis: 2007.5-2010; Mid-Range Truck, Bus: 2007-2010
0445-120-231-H Injector 6 New, Bosch [5263262, 4945969, 3976372; 0445 120 059, 0445 120 231, 0445-120-
231]
ISB/QSB: Automotive, Construction, Bus
121337 Injector oring 6 [3977393]
136145 Injector washer 6 [3976371]
COOLING SYSTEM
3800984-G Water pump 1 Hardened pulley, Brown phenolic impeller; 4891252 pump with seal ring [3800984,
4891252, 4892174, 4892175, 4089142, 2881805, 3959229, 3949889, 5263174,
87803065, 2852114]
AP63533 Water pump 1 [2881804, 68003402AA; 5260263 pump, 3906698 seal; sub for 4955359]
