Input Line Reactor compatible to LG Frequency Inverter
This is DC reactor, which is compatible to LG frequency inverter. DC reactor that are specially designed for many series of LG frequency inverter, such as Stravert-iH, Stravert-iG5, and more. For example, with the working voltage of 3AC 380~460V, our HSL119-L105, and HSL119-L106 For details about parameters of our compatible reactor to series of LG frequency converter, please visit HSLEC website.
Technical parameters
Source |
Motor |
LG Frequency Inverter |
3-Phase Line Reactor |
||||||
Voltage |
Power |
Model |
Output |
Phase |
Ref. No. |
No. |
Ref Price |
||
(V) |
(kW) |
Voltage (V) |
Current A |
Current (A) |
LG |
HSL |
USD |
||
|
0.4 |
004iG- 4 |
380~460 |
1.3 |
1.4 |
|
HSL119-L16 |
1 |
17.65 |
3AC400 |
0.8 |
008iG- 4 |
2.5 |
2.8 |
|
HSL119-L17 |
1 |
17.65 |
|
|
1.5 |
015iG- 4 |
4.0 |
4.4 |
|
HSL119-L18 |
1 |
17.65 |
|
|
2.2 |
022iG- 4 |
5.5 |
6.1 |
|
HSL119-L19 |
2 |
22.06 |
|
|
022S3- 4 |
||||||||
|
3.7 |
037iG- 4 |
8.0 |
8.8 |
|
HSL119-L20 |
3 |
30.90 |
|
Features
1. The line reactor greatly reduces catastrophic drive failures due to transient over-voltage.
2. The low voltage reactor decreases nuisance over-voltage trips due to line transients, drastically:
(1)Utility power factor correction
(2)Switching large AC motor loads
(3)Switching large transformers
(4)High AC line conditions
3. Line-side fuse operation during unsymmetrical voltage sags is reduced to the minimum:
(1)Utility system line-to-ground faults
(2)Unbalanced phase currents
4. The line reactor can also prevent harmonics and effectively improve power factor.
Functions
1. A line reactor can be used for adding line impedance.
2. The inductor also serves to reduce harmonics.
3. It is able to compensate for a low inductance motor.
4. The low voltage reactor acts only as part of a filter to reduce reflected wave.
Data Required With Order Or For Bid Purposes
1. System Voltage (KV)
2. Frequency (Hz)
3. Basic Impulse Level (KV)
4. Reactance/Inductance (Ohms/Micro henries)
5. Continuous Current (A)
6. Short Circuit Levels (Ka) - Time Duration (Sec)
7. Fundamental/Harmonic Frequency levels (Hz)
8. Q Required For Filter Reactors
9. Insulators Supplied Or Not Supplied And TR No. Or Type To Be Used
10. Vertical or Horizontal Mounting
11. Three Phase Side By Side or Vertical Stack Mounting
12. Terminal Configuration
13. Dimensional Limitations
14. Number of Units
The Basic Program Of Testing Includes
1.Routine Tests
2.Impulse Tests
3.Thermal Current Calculation
4.Mechanical Strength Test
5.Impedance and Loss Test
6.Temperature Rise Test
7.Sound Level Test
8.Seismic Analysis
Standard export wooden packing.
Delivery Time
4-30 days after receive the payment
Service Conditions
1. Service Site: Indoor Or Outdoor
2. Ambient Temp.:-40~40 Degree( Or According To Customer's Requirment)
3. Altitude: <=10000m( If It Exceeding To 1000m, Pls Declare In Order).
4. Max. Wind Speed: 35m/S
5. Relative Humidity: <=90%
6. Earthquake Resistant Capability: Horizontal Direction 0.3g Verticle Direction0.15g (Or By Customer's Requirments)
Outline Drawing
Qinhuangdao Huashenglong Electrical Equipment Co., Ltd. (HSLEC), founded in 1992, which integrates design, Development and production in one set, And it is a high-tech enterprise in Hebei Province. As an experienced Dry Type Transformers and Reactors manufacturer, we offer a wide variety High Voltage and Low Voltage power products, including power transformers, distribution transformers, air core reactors, iron core reactors and line reactors and output reactors compatible to variety Frequecny Inverters and Governors. In addition, we also can fulfill your OEM requests
HSLEC primary products are Transformers and Reactors. Reactors which can be divided into high-voltage and low-voltage reactors two categories: High Voltage Reactors including air core series reactors, air core shunt reactors, air core filter reactors, air core currrent limiting reactors and other type iron core reactors; Low voltage reactors including line and output reactors compatible to SIEMENS,EMERSON,FUJI,LG and other brands frequency inverters.
