Specifications of our industrial door
| Door Panels | Panel Style | Finger protection |
| Panel Construction | Steel+PU foam+Steel | |
| Panel Thickness | 40mm/50mm | |
| Panel Max Height | 550mm | |
| Panel Max Length | 12m | |
| Panel Color | White and wood like color,other color can be customized | |
| Panel Surface Style | Flat/ Line / Square | |
| Panel Steel thickness | 0.35mm/0.45mm | |
| Door Hardwares | Tracks style | Double track or Single track |
| Track cover | Available | |
| Track and track cover surface finish | Bright Zinc Galvanized | |
| Hinges and roller brackets surface finish | Bright Zinc Galvanized | |
| Top/bottom stretch | Plastic or Aluminum | |
| Top/Side/Bottom rubber seals | included | |
| Safety system | Spring break safety brackets | Available |
| Cable break safety system | Available | |
| Door Motor | Motor style | Chain |
| Motor Voltage | 110V or 220V | |
| Motor Force | 800N/1000N/1200N/1500N/1800N | |
| Motor speed | 1400--3200r/min | |
| Motor sensor/ Alarming/ wall brackets/ Keypad/ Back battery | available |
Industrial door motor
Different sizes of foam slats
a.Name: garage door
b.Brand:Master
c.Material:coloured-steel plate
d.Structure:sandwich(steel-polyurethane-steel)
e.Thickness:40mm
f.Styles:SF40,SF40S,SN40 (finger protection,nonfinger protection)
g.Surface:woodgrain,orange peel,flush,fold(with rectangle or stripe)
h.Property:heat preservation,heat protection,dust protect
i.Colour:white,red,silver,coffee,mahogany or other solid colours
j.Panel Width:430mm-550mm,adjusted
Length:12m,adjusted
k.Accessories:track,hinge,bearing,bracket,spring,shaft,roller,cable,
Cable drum,handle,pully,lock,seal, motor,opener
Hardware difference
A.Standard equipment (Junior equipment):
(1) Standard Single Track (SST): 1 pair vertical track and 1 pair horizontal track with Jamb bracket, for min headroom 350mm
(2) Standard Double Track (SDT): 1 pair vertical track, 1 pair horizontal track and 1 pair LHR horizontal track, with Jamb bracket, for min headroom 150mm
B.L profile support (Senior equipment)
(3) L profile with Single trackL(LST): 1 pair vertical track, 1 pair horizontal track with L profile support, for min headroom 350mm
(4) L profile with Double track (LDT): 1 pair vertical track, 1 pair horizontal and 1 pair LHR horizontal track with L profile support, for min headroom 200mm
C.Superior equipment
(5) L profile support with Double track (SLDT): 1 pair vertical track, 1 pair horizontal track and 1 pair LHR horizontal with L profile support for min headroom 200mm
ABS Curve instead of steel curve
Plus Spring Anti-breack device
Windows or small door designs sample
The windows can be inserted into the panel to allow daylight to enter your garage, provide it with further uses, such as a workshop or hobby room.
A sectional door can also opens a small pass door, which makes it more convenient to go inside and outside. Please see below picture.
Advantage
- Low MOQ: One set is available for checking our quality first conveniently.
- Good Quality: Your client satisfied on our quality. You can get good reputation from your market and obtain more orders.
- Good Service: Our professional service before and after sale.
- The reasonable price
- Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
- OEM is welcome .
Details:packed in carton with wrapped film or wooden case
Q&A |
|
|
|
|
|
Q1. How can I get a sample of garage door for quality check? |
|
||||
A:1. Please give the exactly size of your samples door, also the color, design , etc.We can according to your specification and make a sample for you. |
|
||||
Q2. How can I get a price of needed garage door? |
|
||||
A: 1. Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements. |
|
||||
2. If you don't know the size and quantity you need, tell us which country does the target market. We will make a quotation according to our experience for different country. |
|
||||
Q3. I don't know the detail information, how can i order this from you. |
|
||||
A: It's the best way if you can send us the size, so we can according to your size to make a sutiable garage doors for check the quality, Also will give you the detail information of ours. If you still have any confusion, just contact us, we would like to be helpful. |
|
||||
Q4. I am a small wholesaler, do you accept small order? | |||||
A: It's no problem if you are a small wholesaler, we would like to grow up with you together. | |||||
Q5. We want be your agent of our area. How to apply for this? | |||||
A: Please send your idea and your profile to any e-mails of us. Lte's cooperate. | |||||
Q6.Can you make OEM service? | |||||
A:Yes. We can accept OEM service. Also we have our own designer team. So it's also welcome to choose our OEM products. | |||||
Q7. Do you have a MAQ requirements? | |||||
A.No. We don't have any special requirements on MOQ. Only 1 set is also available. But if your want more, we would like to give you more discount. | |||||
| |||||
| |||||
Q8. Which kinds of payment you accept? | |||||
A: We usually accept T/T in advance, L/C for large sum, Westion Union, etc. If you prefer other payments terms, please discuss with us. | |||||
Q9. Do you have any certificate of your garage door? | |||||
A:Yes. We have CE Certificate for our garage door series. | |||||
