8leds SMD5050 10-30V automotive led bulb long neck
| Product Code | Base | Voltage | Current | Watts (Typ.) | LED Q'ty | LED Encapsu-lation | CCT(K)/ Color | Lumens (Typ.) |
| 15SR-8ACW-30D-02 | BA15s | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 6622K | 165 |
| 15SR-8AWW-30D-02 | BA15s | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 3032K | 162 |
| Y15R-8ACW-30D-02 | BAY15d | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 6622K | 165 |
| Y15R-8AWW-30D-02 | BAY15d | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 3032K | 162 |
| 15DR-8ACW-30D-02 | BA15d | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 6622K | 165 |
| 15DR-8AWW-30D-02 | BA15d | 10-30VDC | 100mA | 1.3 | 8 | SMD5050 | 3032K | 162 |
Product Description:
The automotive led bulb has been designed for use in place of tungsten lamp in either 12V or 24V systems. The lamp is brighter than a 20W halogen and uses just 1.3Watt. The tungsten bayonet is easily replaced with an LED alternative.
The bayonet fitting is commonly used in awning lights, spot lights, interior light, reading lights and many light fittings in the RVs.
| Beam Angle: | 120° |
| Color Temperature: | 2850-3050K,5650-6000K |
| Base Type: | BA15s BA15d BAY15d |
| Dimensions: | 26.5mm x 42.5mm (incl. base) |
| Lifetime | 50,000 hours |
| Warranty: | 2-Years |
| CRI: | >80 |
| Operating Temperature: | -30~+60 °C |
| Warranty: | 2 years |
| Colours: | White, Green, Blue, Amber, Red. |
| Certification: | CE RoHS Compliant |
| Dimmable: | non-dimmable |
| Polarity Sensitive: | Non-polar |
| IP Rating: | Non-Weatherproof |
Features & Benefits:
1. Constant-current drive topology
2. Very low power consumption
3. Over-voltage protection
4. No radiated heat
5. Wide voltage input range
6. Shockproof - ultra-rugged with no filament to burn out or break
7. Lead and mercury free, no UV output
8. Zero RF emission, surface mount device design
Certificates:
Automotive led bulb have CE RoSH certificaiton
Applications:
1.Boat automotive, RV, motor home, marine and etc
2. Hotel, Entertainment place, Household, office light, , home use light, etc.
Trade Terms:
1 Payment: Western Union or T/T are welcomed.
2 Production lead time for 100-30000pcs:7-15 days
3 Sample of 10-30V automotive led bulb can be delivered in 3days
Our Services:
1) Provide you professional 10-30V automotive led bulb design.
2) Warranty 2 years and maintenance free
3) All your inquiry will be reply in 24 hours in our working day
4) Well-trained and experienced staffs to answer all your enquiries in fluent English.
5) OEM&ODM, any your customized lightings we can help you to design and put into product.
6) Distributorship are offers for your unique design and some our current models.
