Help CenterN Male to BNC Female , Cable Connector,RF Connector, Adaptor
Related Products
-
SMA to TNC Female Adaptor Connector RF AadaptorUS$ 0.5 - 2MOQ: 10 Pieces -
RF Application and Adapter Type SMB Male to N Male rf AdapterUS$ 0.8 - 1.5MOQ: 10 Pieces
-
TNC Male to SMA Female Reverse Polarity AdaptorUS$ 0.5 - 1.8MOQ: 10 Pieces
-
(CE+ROHS)High Quality Low Price RF Adaptor N to BNC Connectors(manufactory)US$ 1 - 3.5MOQ: 10 Pieces
-
N Type Female Plug to BNC Male Jack RF Coaxial Adapter,75ohmUS$ 0.8 - 1.8MOQ: 10 Pieces
Specifications
1.Type:N to BNC
2.male to female,75 ohm
3. supply the products at producer price
4.Socket:beryllium-copper/gold/silver plated
SPECIFICATION
Adaptor is the basic product that used in the connection between the instrument cables with different interface.These are two kinds of them:within-type adaptor and inter-type adaptor.It has the same technical special characteristic with same class product.Within-type adaptor is listed in the catalogue of that product.Our company designs and produces various adaptors with all kinds of specification.They have wide frequency range and low VSWR characteristics.Welcome to visit and choose.
MAJOR TECHNICAL CHARACTERISTICS
Temperature Range |
-55~+155°C(PE Cable-40~+85°C) |
Impedance |
50Ω,75Ω |
Frequency Range |
DC~4GHz |
Working Voltage |
500V r.m.s at sea level |
Withstanding Voltage |
1500V r.m.s at sea level |
Contact resistance |
Center Contact ≤1.5mΩ Outer Contact ≤1mΩ |
Insulation resistance |
≥5000MΩ |
Center conductor retention force |
≥0.57N |
Insertion Loss |
≤0.20 dB/3GHz |
Voltage Standing Wave Ratio |
Straight ≤1.22/3GHz Right angle ≤1.30/3GHz |
Durability(mating) |
≥500times(cycles) |
APPLICABLE STANDARD
MIL-C-39012;
CECC 22120;
IEC 60169-8.
