1.Type:TNC/SMA Adaptor
2.TNC female to SMA female adaptor,50Ohm
3.Good quality,best price
| MAJOR TECHNICAL CHARACTERISTICS | |
| Temperature Range | -55~ +155°C (PE Cable -40~ +85°C) |
| Vibration | 98m/S2 (10~2000Hz) 10g |
| Impedance | 50Ω |
| Frequency range | DC~12.4GHz(Semi-Rigled Cable DC-18GHz) |
| Working Voltage | 335V r.m.s at sea level |
| Withstanding voltage | 1000V r.m.s at sea level |
| Contact resistance |
Center contact<=3m Ω Coter contact<=2.5m Ω |
| Insulation resistance | >=5000MΩ |
| Center conductor retentin force | >=0.28N |
| Coupling nut retentin force | >=180N |
| Insertin loss | <=0.15 dB/6GHz |
| Voltage Standing Wave Ratio |
Straight flexible cable <=1.10+0.02f semi-rigid cable <=1.07+0.018f Right Angle flexible cabl <=1.20+0.03f semi-rigid cable <=1.17+0.02f |
| Durability(mating) | >=500 times (cycles) |
| MATERIAL & PLATING | ||
| Body | brass | gold plated |
| pin contact | brass | gold plated |
| socket contact | beryllium-copper | gold plated |
| resilient contact | beryllium-copper | gold plated |
| insulator | PTFE | |
| crimp ferrule | copper alloy | nickel or gold plated |
| o-ring sealing | 6146 silicone rubber | |
MIL-C-39012;
CECC 22110;
IEC-60169-15.
According to the national and professional standards(GB&JS), we produce all kinds of RF coaxial connector:
SMA, SMB, SMC, BNC, TNC, N, 7/16(L29), 1.6/5.6(L9),MCX, MMCX, SSMA, SSMB, SSMC, SMZ, MC CARD(C2),UHF, MINI UHF, F, RCA etc.
And assembly of antenna, cable-package, audio and video connector, big specification connector of feeder line.
All kinds of adapter, impedance converter, fixed attenuator, termination loading, arrester.
All kinds of RF coaxial cable—SYV, SFF, RG, semi-rigid, etc.
• The aim of our company is to provide you outstanding quality, fast delivery, reasonable price, excellent after-sales.
• Please contact us for more details.
