Sugar Cane Harvester, Sugarcane Harvester, Combine Sugarcane Harvester

Name: Sugar Cane Harvester, Sugarcane Harvester, Combine Sugarcane Harvester
Brand: SQINDUSTRY
SKU: 104646187
Availability: InStock

US$ 65,000 - 70,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Type:

Combine Harvester

Usage:

Other, sugar cane harvester

Shanghai Sheng Qian Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Combine Harvester

Usage Other, sugar cane harvester

Place of Origin Shanghai, China

Brand Name SQINDUSTRY

Model Number SQCH03

Certificate CE

sugar cane harvester

1)type: Whole-stalk harvesting, conveying, leaf peeling-off, separating sugar cane and leaves

2)operator: Single-person seat driving operation

3)Engine Model: 6CTA8.3-C260

4)Power (KW/HP)/Speed (r/min): 194kw/260hp/2200 r/min

5)Wheel Tread(mm)Front Wheel: 1795, Rear Wheel: 1810. Wheel Base (mm): 2200mm

6)Whole size(m): 8.383(length)*1.9(width)*3.9(high)

7)Vehicle Clearance Circle (m): 11mm

8)Mininum Ground Clearance (mm): 230mm

9) Cutter lifting angle adjusting range (Degree): 18

10)Applicable row spacing (m): >1.2

11)Number of rows harvested (Row): 1

12)Gearbox Steps stepless speed adjusting gear,1-step back-up

13)Driving type of Traveling: Hydraulic rear wheel drive

Item	Harvesting with leaves	Harvesting without leaves
Qualification of cutting height (%)	≥90.0	≥90.0
Ratoon broken rate (%)	≤15.0	≤15.0
Impurity rate of single sugar cane (weight %)	≤4.0	≤4.0
The total loss rate (%)	≤4.0	≤5.0
Cane stalk qualification rate (%)	≥95.0	≥95.0
Net working hour productivity (ton/hour)	≥20-35	≥15-25
diesel oil (L/h)	63	65
