75KW(102HP) Sugarcane Loader With 1600kg Capacity
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, sugarcane loader
Usage:
Other, sugarcane loader
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20ton/h Capacity Combine Sugarcane HarvesterNegotiableMOQ: 1 Unit -
Sugar Cane Press MachineNegotiableMOQ: 1 Unit
-
1.2 Ton/h Sugarcane Leaf Stripper(remove the Leaves of Sugarcane Without Hurt)NegotiableMOQ: 1 Unit
-
194kw/260hp Sugarcane Combine HarvesterNegotiableMOQ: 1 Unit
-
194kw/260hp Sugarcane HarvesterNegotiableMOQ: 1 Unit
Condition
New
Type
Other, sugarcane loader
Usage
Other, sugarcane loader
Place of Origin
Shanghai, China
Brand Name
SQINDUSTRY
Model Number
SQCL04
Certificate
Other, ISO9001: 2008, GB/T 19001-2008
Specifications
sugarcane loader1. Motor: 75KW(102HP)
2. Max loading weight: 1600KG
3. Max. Height of loading: 5.4m
sugarcane loader
- Engine: Adopt Cummins diesel engine, excellent performance, low fuel consumption, low noise, large power reserves, long stroke,.
- Oil tube: Choose high-pressure rubber pipe imported from Italy, which suits all the bad working environment, antiquake, anti-loose, stand fire.
- Hydraulic working system: taking advanced of foreign advanced technology, it can reduce wobble with buffer function, and the machine service life can be extend.
- Traveling system: transmission giving infinitely variable speed in all of ranges, hydraulic braking, working and walking.
- Structure: Choose the domestic manganese steel with excellent quality, improving the strength of structure in a high level, which guarantee the safety of traveling and construction.
- Surface treatment: derusting with large size shot blast machine, to change welding stress.
- Surface spray coating: ant rusting paint, finishing paint.
- The process of welding: carbon dioxide MIG welding.
- Working table controlled by microcomputer, water temperature, oil temperature, current, work timing are all insight.
- Famous brand hydraulic components are adopted, of which the operating life is long, the power is driving and the operating speed is fast.
- Prepositive push piller, convenient for collection
- Oil return filter is set in oil return pipeline to guarantee the cleanness of hydraulic oil.
- Ascendant performance of complete appliance, with extraordinary operation efficiency.
- Standard equipment: 12Volt direct electric starting,23.1*26/10PR,four wheels drived, more powerful, rear axle steering, hydraulic control, dual articulated boom arrangement, push piller, simple cab room.
Maximum grapple height |
5400mm |
Maximum dumping height |
5300mm |
Maximum grapple Radius |
5300mm |
Engine Model |
4102 |
Rated Power |
75kw(102HP ) |
Engine brand |
Cummins |
Total Machine Weight |
7600kg |
Grab Capacity |
1200-1300 kg |
Working Efficiency |
3000kg/min |
Working Times |
3/min |
Hydraulic System Working Pressure |
20Mpa |
Maximum Flux |
63ml/r/63 ml/r |
Slope |
25% |
Maximum Hauling Force |
29KN |
Walking Speed |
≤25km/h |
Boon rotation Angle |
129° |
Overall dimension(L×W×H) |
4900*2600*2500mm |
Min. Ground Clearance |
580mm |
Tread |
2000mm |
Wheel base |
2600mm |
Tires |
23.1*26/10PR |
Fuel consumption |
≤225g/kw.h |
Container |
1 set/40HQ |
Free Spare Parts
type |
name |
spec. |
No. |
quick-wear part |
grease seal |
φ80 |
1 |
φ100 |
1 |
||
O rings |
30×3.1 |
5 |
|
26×3.5 |
5 |
||
24×2.4 |
5 |
||
grease fitting |
M10×1 |
5 |
|
tools |
Grease gun |
|
1 |
open spanner |
6--32 |
1 |
|
screwdriver |
flat blade tip |
1 |
|
cross-shaped |
1 |
||
hammer |
|
1 |
|
spare parts of engine |
wire cutter |
|
1 |
socket head wrench |
φ5 |
1 |
|
Cylinder head of cushion |
φ6 |
1 |
|
φ12 |
1 |
||
|
1 |
||
box of spare parts for fuel engine |
|
1 |
|
user manual |
|
1 |
|
documents |
certificate |
|
1 |
Warranty card |
|
1 |
