•Major characteristics:
Double-locked, fool-proofing assembly with the color and the structure
The connector is be protected by the cap .
Easy to assembly
Many difference between the connector and the cap.
• The product technical characteristics:
Body: Brass, Ni-plated
Socket: beryllium-copper, Gold-plated
Pin contact: Brass
Insulator: PTFE
Crimp ferrule: brass, Ni-plated
O-ring: beryllium-copper
Shell: PA66+30%GF
• Technical characteristics
Impedance: 50Ω
Frequency Range: 4GHz
Withstanding Voltage: 1000V(RMS)
Contact resistance:
Center contact: ≤ 20m
Outer contact: ≤10m
Insulation: ≥1,000MΩ
VSWR: DC - 2GHz<1.2
• Mechanical characteristics:
Assembly: locked
Durability: ≥ 500 cycles
Temperature: - 40 - +85°C
| Model | Color |
| A | Black |
| B | White |
| C | Blue |
| D | Bordeaux-violet |
| E | Green |
| F | Brown |
| G | Grey |
| H | Violet |
| I | Beige |
| K | Curry |
| Z | Waterbleu |
| L | Carmine Red |
| M | Pastel Orange |
| N | Pastel Green |
Our service advantage
1) factory sell directly & a good service
2) long-term, strong and steady supplying ability
3) delivery time: 5-7 working days
4) ex-factory price and competitive price
5) do as your requirements on package, brand or other designs
