ISO1600 Film Safety Guarantee Safety Equipment Supplied by Factory

ISO1600 Film Safety Guarantee Safety Equipment Supplied by Factory thumbnail-1
ISO1600 Film Safety Guarantee Safety Equipment Supplied by Factory photo-1
Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MCD
Model Number:
MCD-6550
Contact Supplier Request Quote Chat Now
Shenzhen MCD Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MCD
Model Number MCD-6550

Specifications

1.Conveyor Speed: 0.22m/s
2.Conveyor Max Load: 170kg
3.Penetration: 34mm Steel
4.Film Safety Guarantee ISO1600 Film

ISO1600 Film Safety Guarantee safety Equipment Supplied by factory



Specification:

  • Tunnel Size: 650(W)*500(H)mm
  • Conveyor Speed: 0.22m/s
  • Conveyor Max Load: 170kg
  • Dose per Inspection <1.4Gy/h
  • Resolution < 0.0787mm Copper Wire
  • Spatial resolution Level: dia1.0mm,
  • Vertical: dia1.0mm
  • Penetrate resolution: Dia 0.254mm
  • Penetration: 34mm Steel
  • Film Safety: Guarantee ISO1600 Film
  • X-ray Leakage: <0.05 μGy/h (at a distance of 5cm From external housing

X-ray Generator

  • Generate direct: Upward
  • Generate anger: 80 degree
  • Anode Voltage: 100~160Kv
  • Anode power: 0.4 to 1.2mA
  • Cooling / Duty Cycle: Oil Cooling /100%

Image System

  • X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
  • Monitor: High Resolution Color, LCD Accord, 17 inch
  • Image Processing: Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.
  • Image Grey Level: 4096
  • Image Max Resolution: 1024 * 1280 pixel
  • Image Processing: 24bit for processing real time
  • Image storage: Storage 60000 pictures in real time
  • Zones & Zoom: 1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation
  • Multi-energetic distinguish objects : organic objects in orange, inorganic objects in blue, mixture in green
  • High-energy/low energy : switch from high energy to low energy
  • Assist to detect drug and explosive powder

Installation Data

  • Operation temperature/Humidity: 0°C-45°C/20%-95%(non-condensing)
  • Storage Temperature/Humidity: -20°C-60°C/20%-95%(non-condensing)
  • Operation Power: 220VAC(±10%)50±3Hz
  • Power Consumption: 1.0 KW (max), 0.7KW(working)
  • Noise: <58db

Features

  • Sound and light alarms
  • Network Interface: Can connect local area networks, multiple terminals can check luggage’s at the same time.
  • Safer-ray: Ray fired automatic control, to avoid misusing launching.
  • Simple mouse control: can directly control the equipment without the keyboard and the working table.
  • One shutdown control button: You just need to rotate the key and the equipment will automatic power off safely, no need for complex multi-step operation, more convenient and simpler.
  • Eagle Eye: Current region can be reviewed conviently in enlarged status.
  • Fault self-diagnosis: Automatically determine the failure and give prompt information, easy to maintain.

ISO1600 Film Safety Guarantee safety Equipment Supplied by factory

Application:

         Used in the factory testing of security products and business units such as: electronic factories, shoe factories, toy factories, courts, railway stations, and event bag, line security management package



ISO1600 Film Safety Guarantee safety Equipment Supplied by factory



Our company:



ISO1600 Film Safety Guarantee safety Equipment Supplied by factory

Certification:



ISO1600 Film Safety Guarantee safety Equipment Supplied by factory
