Wuxi Shenda SHD1600 big plastic pipe HDPE welding machine
SHD1600 plastic pipe welding machine
Detailed Product Description:
Application :
PE pipe welding machine is suitable for butt welding of plastic pipes and fittin g s made of PE,PP and PVDF in construction site or workshop.
Features :
1. The machine body is equipped with four main clamps with the third clamp axially moved and adjusted.
2. Removable PTFE coated heater with separate temperature control system.
3. Electric facer with reversible double cutting edge blade.
4. Hydraulic unit provides welding machine with compressing power.
5. Be made of lightweight and high strength material; simple structure and easy to operate.
6. Low starting pressure ensures reliable welding quality of small pipes.
7. Separate two-channel timer shows time in soaking and cooling phase.
8. High-accurate and shockproof pressure meter indicates clearer readings.
Technical specifications :
Model |
SHD1600 |
Pipe Size(mm) |
1000,1200,1400,1600 |
Heating Plate Max. Temp |
270°C |
Temp. deviation in surface(170~250°C) |
<±7°C |
Pressure adjustable Ranges |
0-25Mpa |
Working Voltage |
380V,50Hz |
Heating plate power |
42KW |
Planing tool r Power |
5.5KW |
Hydraulic unit power |
3.0KW |
Total power |
50.5KW |
Gross weight |
9000Kg |
The whole machine consist s of machine body, hydraulic unit, facer , heater , support for heater & facer .
On request (accessories):
1. Flange stub end holder
2. Data logger
3. Electrical hoist
Who we are ?
Our company WUXI SHENGDA PLASTIC PIPES WELDING MACHINE CO., LTD is the leader manufacturer of buttfusion equipment in China. We occupy the 70% domestic market and export to more than 45 countries. We specialize in producing a complete range of international standard butt fusion equipment including field welding machine, workshop fitting machine, pipe saw, all the optional parts and tools required under the ISO9001 system and approved to CE standards by SGS.
In 2015, my company joined German ROTHENBERGER tools group, becoming one of the more than 50 companies under the first European big pipe tool production and sellers. And companies from the site moved to focus on economic development zone of jiangsu province - wuxi hudai industrial zone - joint road (north) 9 D building, with the German headquarters and subsidiaries throughout the world to work together, we will further development of domestic and international market.
Former:
Now:
WORKFLOW
These are our finished product:
After inspection the each parts of the machine is packed in plastic bags and then carefully packed in plywooden cases
Our exhibition in Shanghai and Gaungzhou
We have good after-sale service and we have a group of experienced engineers, available to help you solve any difficult problems!
Wuxi Shengda, your best and wise choise.
Our quality certificate:
