Wall Mounted Interior Protective Safety Corner Guards
1. Description
Corners are one of the most vulnerable areas of a building. Damaged corners can harbour dirt and bacteria and are difficult to clean. Corner Protectors offer a highly effective and inexpensive way to protect vulnerable corners from damage, Corner guards can be installed onto damaged corners, concealing existing damage and preventing further damage. Surface mounted, high-impact edge guard for metals protect exposed and vulnerable corners from the roughest treatment.
They are all available in 90° and 135° rigid Vinyl, co-extrusions of rigid and flexible vinyl and 90° or 135°Aluminum. Double sided tape, adhesive or screws can be used for mounting.
2. Feathers
a) Corner Guards have high impact resistance.
b) The color is permanent and easily cleaned with standard cleaning materials.
c) Achieve a finished look with color coordinated top and bottom caps included with every edge guard for metal unit
d) Some edge guard for metals are manufactured with a hidden aluminum retainer to take the brunt of any impact, dispersing the action.
3. Specification
| Product name | Corner guard |
| Structure | Vinyl cover + inner aluminum retainer + Caps |
| Size | Width of Vinyl cover: 50mm |
|
Thickness of Vinyl cover: 2.0mm Thickness of Aluminum support: 1.2mm, 1.4mm, 1.6mm, 1.8mm | |
| Length: optional from 1 meter to 5 meters | |
| Weight | Panel:0.40kg/m |
|
Aluminum A:0.83kg/m(1.4mm)0.98kg/m(1.6mm)1.26kg/m(1.8mm)1.3kg/m(2.0mm) B:0.9kg/m(1.6mm);1.1kg/m(1.8mm) | |
| Color | As you request, you can choose any color you like, color chart can be provided. |
| Configuration | 1.5m edge guard for metal=1.5 aluminum retainer=2 pcs caps |
3.Accessories
1. PVC Cover: It is the surface part of the wall mounted plastic Corner guard. Material is Vinyl (PVC).
2. Aluminum Alloy Retainer : It is under the PVC cover, to support the covers.
3. ABS End Cap: One side is put into the wall mounted PVC handrails to cover the end;
4. Application
Corner guard leads the industry in its breadth of application, with suitable options for protecting every type of facility and every application. Corner guards are ideal for reducing maintenance costs and maintaining interior appearances in environments ranging from education, healthcare, municipal, hotels/motels, commercial kitchens, shower areas, l and pharmaceutical through to commercial office, retail, hospitality and transport.
5.Corner Guards Other Models
More models can be provided with different sizes, shapes and colors. Any size and color can be customized.
Model No. |
Diemension/Size in mm |
Thickness (mm) |
Mateiral |
Degree |
||
Width |
Length |
Vinyl Cover |
Al-alloy Retainer |
|||
HS-005 |
50 |
1000-5000 |
7 |
/ |
soft pvc |
90 |
HS-005A |
50 |
1000-5000 |
5 |
/ |
soft pvc |
90 |
HS-603A |
30 |
1000-5000 |
2 |
/ |
hard pvc |
90 |
HS-605A |
50 |
1000-5000 |
2 |
/ |
hard pvc |
90 |
HS-607A |
70 |
1000-5000 |
2 |
/ |
hard pvc |
90 |
HS-605B |
50 |
1000-5000 |
2 |
1.2/1.4 / 1.8/2.0 |
hard pvc+aluminum |
90 |
HS-607B |
70 |
1000-5000 |
2 |
1.2/1.4 / 1.8/2.0 |
hard pvc+aluminum |
90 |
HS-635B |
50 |
1000-5000 |
2 |
1.2/1.4 / 1.8/2.0 |
hard pvc+aluminum |
135 |
6.Packaging And Delivery
Inner plastic film, outer cartons or according to customer’s special request
Panel: plastic film + carton 20pcs/carton
Aluminum: plastic film + carton 20pcs/carton
7.Certifications
Our product has gotten the SGS Certificate and be authorized by TUV
8.Our Customers
Our products are expoted to more than 60 contries, such as Korean, Japan, Singapore, Australia, USA, Canada, UK, Mexico, Brazil, Spain, Russia, India, Vietnam, Indonesia, Germany, France, UAE, Turkey, South Africa, etc
9.Contact Us
Any color, shape, size, can be customized according to your request.
Leave an inquiry to know more details about Free sample, Price, Packing, Shipping and Discount.
Your questions will be very welcome, please feel free to contact us.
Thank you for your visiting
