Efficient CNC WXC80S Peeling Machines for Round Steel

Name: Efficient CNC WXC80S Peeling Machines for Round Steel
Brand: haige
SKU: 104609491
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Yantai Haige Machine Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 80(mm)

Place of Origin Shandong, China

Brand Name haige

Model Number WXC80S

Voltage 380(V)

Power(W) 95(kw)

Dimension(L*W*H) 3.5*3.5*2.4(m)

Weight 8.5(t)

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

WXC80S Diameters:

CENTERLESS TURNING MACHINE
CENTERLESS TURNING MACHINE
MODEL		WXC80S
RAW MATERIALS	Turning Range(mm)	Φ21˜Φ85
	Raw Material Length(mm)	≥2200
	Tensile Strenth(Mpa)	≤1100
	Surface Hardness	≤HB390(≤HRC42)
	Curvature(mm/m)	≤1.50
	Diameter Tolerance	≤+IT15/2 or more or less 1% of diameter tolerance
	Roundness	≤50% of the diameter tolerance
	Surface Roughness(Ra)	≤25˜50um
FINISHED GOODS	Diameter Range	Φ20˜Φ80
	Unilateral Turning Depth (mm)	0.35˜1.50
	Diameter Tolerance	≤IT10
	Surface Roughness(Ra)	≤6.3um
	Curvature(mm/m)	≤1.5
	Roundness	50% of the diameter tolerance
Turning Speed(m/min)	1.0˜6.0 (reduce feed speed for continuous materials)
Cutter Speed	290˜800 (Hexapole) 430˜1200 (Titanium Turning)
Main Motor Power(KW)	75
Feed Motor Power(KW)	5.5(Pinch of raw materials)+0.75(Finished out)
Main Motor Dimentions(m)	3.5 X 3.5 X 2.43
Auxiliary Equipment Dimention(m)	15.5 X 5.0 X 2.4
Main Motor Weight (including auxiliary weight) (t)	8.5 (12.0)
Total Installed Capacity(KW)	95
Compressed Air Supply(user-owned)	0.5---0.8Mpa,3m³/min, Including Two Oil--Water Seperator
