Home > Packaging & Printing > Packing Machinery > Packing Line > Automatic Corrugated Flexo Printer Slotter Die Cutter

Automatic Corrugated Flexo Printer Slotter Die Cutter

Name: Automatic Corrugated Flexo Printer Slotter Die Cutter
Brand: Qisheng
SKU: 104608479
Availability: InStock

Automatic Corrugated Flexo Printer Slotter Die Cutter thumbnail-1

Automatic Corrugated Flexo Printer Slotter Die Cutter photo-1

US$ 100,000 - 218,300 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Other, Machinery & Hardware

Packaging Type:

Cartons

Contact Supplier Request Quote Chat Now

Shanghai Qisheng Packing Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Other, Machinery & Hardware

Packaging Type Cartons

Packaging Material Paper

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 22 kw

Place of Origin Shanghai, China

Brand Name Qisheng

Model Number GYMK

Dimension(L*W*H) 8500*6900*4500

Weight 20000kg

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Automatic corrugated flexo printer slotter die cutter
1. one year warranty
2.good service
3.export to many countries

Automatic corrugated flexo printer slotter die cutter

General features

The machine is manufactured with the aims to meet the tough operation requirement,reliable ,good function and safe,Hence ,standard parts ,fast set-up and easy to operate are our advantages

Best materical and part are used

Gest train are hardened and ground (hardness>60HRC)

Automatic zero setting and return to the pre-set position after open

Chrome plated shafts

The machine is also equipped with an automatic lubricating system that keeps the lubricant levels in each unit uniform at all times

PLC with multifunction touch screen control

European standard specifications for all electrical and pneumatic components

Repeat orders storing and recalling for fast set-up

Main motor is inter-locked,only operatable when units are locked close

automatic feeder flexo printer slotter paper box cutter

Detailed Product Description

Feeder Unit	Printer Unit
Feeder Unit 1. Printing operation is motorized with pneumatically locking system, feeding and overload real time display or alarms. 2. Included anvil cylinder for lead edge feeding, ventilation volume by power frequency control and motorized movement for side, gate and back deflection plates.(guides) 3. Perform more stability for think or wrapped sheet or when production speeding up needed machine may be controlled by power frequency. 4. Automatically feeding system with anilox roller to avoid sheet wasting. Display feeding rate, sheet counter number with skip feeding option.	Printer Unit 1. Printing disposition is automatically setting and displaying. 2. Easy to mount the Quick Lock plate . 3. Anvil cylinder will do quick transverse movement with quick self-locking system to production gap.. 4. Anilox roller will scrap printing ink uniformly in providing top printing quality. 5. Included fixing positioning system to feeding sheet, re-setting original position with memory and solenoid brake device.
Slotter Unit	Rotary Die Cutter Unit
Slotter Unit The horizontal movement for anvil cylinder, leading feeding system and slotter knives holder will be controlled by PLC program. Computerized control and monitor system will provide purchase or job order memory and quick change by touching screen and control button when necessary. The linear guide rail will assure precise displacement and sharp slotting. Include protection device for safe movement to knives holder. Unique ejected device for wastepaper removal.	Rotary Die Cutter Unit100mm16,25.4mm. Die nip clearance is setting by motorized mode with digital display. Included horizontal movement holder to rubber roller. Included imported rubber pad to easy and quick replace for long operation life. Speed difference compensation system will assure uniformly and precisely feeding. Bolts holes space to die plates will be to axial 100mm and 16 radical equal units for die cutter height 25.4mm.
selective buying:	Ceramic anilox,Doctor blades system, Die-cutting anvil roll renew div

Performance Technical Parameter

standard	900*2000	900*2400	1200*2400	1200*2800	1400*2800	1600*2800
Machine max speed	180	180	160	160	150	140
Machine economic printing speed (pcs/min)	140	140	130	130	120	110
Max paper feeding size(mm)	1000*2000	1000*2400	1200*2400	1200*2800	1400*2800	1600*2800
Min paper feeding size(mm)	280*685	280*685	300*685	300*685	350*685	400*685
Paper feeding thickness range (mm)	2.5-12	2.5-12	2.5-12	2.5-12	2.5-12	2.5-12
Max printing area(mm)	950*2000	950*2400	1150*2400	1150*2800	1350*2800	1550*2800
Standard printing forme thickness (mm)	7.2	7.2	7.2	7.2	7.2	7.2
Production power (kw)	22	22	30	30	35	40
Total power(kw)	40	40	45	45	45	50
