From Wire to Bar
basic composition:
| Loader | 1set |
| Uncoiling machine | 1set |
| Pre-straightener | 1set |
| Peeling machine | 1set |
| polishing machine | 1set |
| coiling machine | 1set |
Process Description
Loader→Uncoil machine→Centerless lathe→Cutting machine→Charging basket
Introduction of Composition
There are two parts of a peeling machine,main machine and auxiliary machine.
Main machine consists of the bed,main bearings,air/oil lubrication system,front-clamping pinch feeding and rear-clamping extracting,front guide and middle-rear guide system,main driving system etc.
Auxiliary machine :loader and unloader device.
Application
1.ferrous material:stainless steel,bearing steel,spring steel,tool steel,structural steel,
free cutting steel,valve steel,pinion/gear steel.etc
2.nonferrous metal:copper alloy,titanium alloy,magnesium alloy,titanium alloy,
magnesium alloy,aluminum alloy.etc
Advantages
1.When processing over-length bar,Centerless Lathe has incomparable advantages.Ordinary lathe is good at
processing short bar.But there is a great restriction for processing long shaft.
In thoery,Centerless Lathe can process the bar of infinite length.
2.Centerless Lathe is not only processing bar,also Wire rod.Including from wire rod
to wire rod and from wire rod to bar that the ordinary lathe can't do it.
3.Processing speed 1-12m/min,the working efficiency of Centerless Lathe is dozens
of times of the ordinary lathe.
4.High precision,after peeling,tolerance of diameter reach≤IT9,
surface roughness Ra≤6.3μm.But after straightening,Ra≤0.8μm.
We have exported to the following countries: Europe and the United States, Russia, Belarus, Pakistan, South Korea, North Korea, India, Vietnam, Taiwan, South Africa, Brazil, Thailand, etc.
We have rich experience in export packaging with professional packaging and professional packing staff. Multilayer packaging is adopted with critical area wrapped with moisture proof and shock proof film, plywood box, or wood box and tray. Multiple reinforcement measures is applied to ensure the solid fixation of equipment on packing box and tray, and the stability of equipment in the container.
- The first layer: wrapped with foam film and stretch film for the special components for the sake of avoiding moisture.
-
Second layer: adopting small square plywood block and strapping belt to fix the machine inside the plywood box
- Third layer: the machine itself has screw fixing holes, so it can be tightly fixed on the bottom of the plywood box through screw and nut.
- Fourth layer: inside the container, the gap between machine parts are filled with compact layout to avoid shaking. At the same time, reinforcing between the bottom of the container and plywood boxes once again, furthermore using hanging steel wire protection.
Our company regards quality of products as the life. It has passed and strictly enforced the ISO9001 international quality system certification.Depending on strong software&hardware facilities and strict quality control, the company has passed the inspection and acceptance of the State Administration for Entry-Exit Inspection and Quarantine Bureau and won the centerless lathe " Export Quality License" as well as straightening machine " Export Quality License".
If you have any questions, please feel free to contact us at the following:
