Yantai Haige machine tools Co.,Ltd whose area is more than 2000m². There are one hundred and forty staffs working in the factory. The factory is mainly engaged in producing and selling peeling machines(centerless lathes), straightening machines, polishing machines(abrasive belt machines), auxiliary machines and other processing and finishing equipment for steel(bright steel) for more than ten years.
Our automatic refined finishing equipment, including the bar peeling machine and straightening machine are at the top-level in this field,no matter for design concept, technical level, production scale,product quality, or for after-service. The production quantity and market share rank the first in China.
Overseas service is available !!!
A. Warranty period: 1 year,except for fast-wearing parts.
B. Reply your inquiry in 24 working hours.
C.Customized design is available. OEM& ODM are welcomed.
D. If necessary,we can dispatch our well-trained and professional engineers to our customers' factory to help them install and debug the equipment.
E.Special discount can be provided to our distributor.
Finished Products
Application Field
1.Bright steel 2.Hydraulics 3.Machining 4.Auto parts
5. Springs 6. Fasteners 7. Bearings
8.Non-ferrous metals,such as copper, titanium, magnesium, aluminum,etc.
Main Technical Parameters
MODEL |
WXC160S |
||
|
RAW
|
Diameter Range(mm) |
Φ50~Φ160 |
|
Raw Material Length(mm) |
≥4000 |
||
Tensile Strength(Mpa) |
≤1100 |
||
Surface Hardness |
≤HB320 |
||
Curvature(mm/m) |
≤1.50 |
||
Diameter Tolerance |
According to GB 702-2004 second group |
||
Roundness(mm) |
≤50% of the diameter tolerance |
||
Surface Roughness(Ra) |
≤25-50μm |
||
|
FINISHED
|
Diameter Range |
Φ49~Φ155 |
|
Unilateral Turning Depth (mm) |
1~5 |
||
Diameter Tolerance |
≤h9 (standard tolerance grade) |
||
Surface Roughness(Ra) |
≤6.3μm |
||
Roundness(mm) |
≤0.05 |
||
Feeding Cutting Speed(m/min) |
0.3-5 (for continuous chips and high strength and hardness should reduce the cutting speed) |
||
Cutter Head Rotational Speed(rpm) |
60~800 |
||
Host Machine Motor Power(KW) |
160 |
||
Auxiliary Machine Motor Power(KW) |
15 |
||
|
Host Machine Outline Dimensions (Length*Width*Height) m |
5.5m * 3m * 2.5m |
||
|
Full Set Machine Outline Dimensions (Including auxiliary) (Length*Width*Height) m |
18m X 3.5m X 3m |
||
Host Machine Weight |
30 (20) |
||
Total Installed Capacity(KW) |
210 |
||
|
Compressed Air Source (users prepare by themselves) |
0.5~0.8MPa,1.8m3/min,more than 0.8 m3 gasholder, two-stage oil-water separator and compressed air freezing drier |
||
Series WXC Centerless Lathe includes Semi-automatic hydraulic and CNC type.
The machine’s features are as follows:
When processing over-length bar,centerless lathe has incomparable advantages.
Centerless Lathe is not only processing Bar,also Wire Rod.
Processing speed 1~12m/min,the working efficiency of centerless lathe is dozens of times of the ordinary lathe.
High Precision,after peeling,diameter tolerance can reach ≤h9,surface roughness(Ra)≤6.3μm.
Semi-automatic Hydraulic Peeling Machine
CNC Bar Peeling Machine
During processing,the bar itself doesn’t rotate.The cutter head drives the tools rotating at high speed to peel the surface of the bar.After peeling,the bar keeps walking straight ahead.
Inside taking multi protection measures:
The first layer
wrapping with foam film and stretch film for the special components, in order to avoid moisture.
Second layer
inside of plywood box, adopting small square plywood block and strapping belt to fix.
Third layer
the machine itself has screw fixing holes, so it can be tightly fixed on the bottom of the plywood box through screw and nut.
Fourth layer
in a container, by compact layout, reducing the gap between boxes to avoid shaking. At the same time, reinforcing between the bottom of the container and plywood boxes once again, furthermore using hanging steel wire protection.
Outside wooden case with export fumigation
Any questions,please feel free to contact me.I will give you soon reply.
