Common rail injector/pump test bench CR3000A-708

FOB Price

USD $5,000 - $8,000 / Set

1 Set(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Voltage	220V/380V	Power	7.5KW,11KW,15KW,18.5KW,22KW
Certification	CE/ISO	Applicable Models	AUTO CAR
Model Number	CR3000A	Warranty	1 Years

Product Description

Specifications

Common rail injector/pump test bench CR3000A-708

it have common rail data inside. show the test result by computer

CR3000A-708 COMMON RAIL TEST BENCH

Interface:

Optional Fuction:

1,One flow sensor(Injection,return oil.turn test)

2, Two Flow Sensors(Recommend,test fast,Injection,return oil ,test at the same time)

3,Weight Sensor(Many injectors can tested at the same time,Test easily and quickly,Low requirements on temperature and oil quality)

4,DRV Valve And Pump Delivery Sensor,Used in CR PUMP Testing.

5,Can Test Denso HP0 pump.

6, Can Test Bosch,Siemens piezo Injectors

7,With BOSCH CP1 PUMP

8,Injectors Mounting bracket, convenient and reliable injector clamping

CR3000A-708 COMMON RAIL TEST BENCH is the professional test bench which is used for testing common rail system,

can test common rail pump,common rail injector at same time.
1,Pump testing: pump delivery, pressure,PVC working status, leakage of itself,
2,Injector testing: leakage, injection oil quantity and back oil quantity(pre-injection,Idling, emissions, full load)
3,it can test pressure sensor,and DRV valve
4. Supports system: BOSCH,DELPHI,DENSO,SIEMENS
5. Testing data inside( pump and injector)
6. Electronic fuel delivery measuring, automatic detection.
Technical parameters
1.Motor power: 7.5KW, 11KW, 15KW, 18.5KW
2. Electronic power: 3 PHASE 380V or 3 PHASE 220V
3. Motor speed: 0-4000RPM
4. Presure adjustment: 0-2000bar
5. Flow testing range: 0-600ml/1000times
6.Flow measurement accuracy:0.1ml
7. Temperature range: 40+-2
8. Cooling system: fan or forced cooling
