Simple Common Rail Injector Tester

Simple Common Rail Injector Tester photo-1
Simple Common Rail Injector Tester photo-2
Simple Common Rail Injector Tester photo-3
Simple Common Rail Injector Tester photo-4
Simple Common Rail Injector Tester photo-5
Simple Common Rail Injector Tester photo-6
US$ 310 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
nantai
Model Number:
QCM400
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name nantai
Model Number QCM400
Warranty 1 Years

1. Introduction

1.1 Description



CR-1000 high-pressure common rail injector controller function is to mimic the engine ECU (Engine Control Unit), while providing Bosch, Denso, Delphi and other common-rail system control signal to drive the high-pressure common rail fuel injection pumps and high-pressure common rail device to work, drive signal parameters users can set their own situation, and saved in groups, to facilitate the maintenance staff working on high-pressure common rail system and maintenance of the state to judge.

1.2 System Application:



The system is suitable for detection of BOSCH, DENSO and DELPHI common rail injectors.

 Such as the type of Electromagnetic injectors. It also can test 1 common rail injectors in one time.



 1.3 Main Functions:



  1. Detection of the common rail injectors: Clean, pre-injection, main injectionthe maximum injection, minimumstart)spraying, return oil quantity.
  2. Cleaning of nozzles
  3. Detection: Common rail pressure sensor, pressure regulator.
  4. Testing environment: Oil temperature regulation, counting measure, adjust the common rail pressure, also can adjust the injection pulse width and duty cycle.

Support system: BOSCH, DELPHI, DENSO



it Is used to adjust and calibrate the injection nozzle opening pressure and to carry out leakage,

spray pattern and chatter characteristic tests.
For nozzle size R, S and T.
In basic design with 0-60 Mpa (0-600 bar) pressure gauge.
In conjunction with a specially ordered pressure gauge, this tester can also be

used for testing light crude oil injection valves.
