automatic brass bar rod peeling machine
brass rod surface prestraightening -- peeling-- precision straightening-- polishing
Yantai Haige Machine Tools Co., Ltd is a professional manufacturer of round steel bar ourside diameter peeling machine and surface two-rolls straightening machine and bar automatic production line and cylinder processing equipment.
Including woking videos as follows:
if you can't open the links in you country, please feel free to contact me ---Lily Skype ID: haige.lily
1. Round bar surface peeling turning and straightening machine
2. Round bar surface processing automtatic production line
/programs/view/9KlXb6WBqso/
3. Cyinder processing equipment, including cnc skiving roller burnishing machine and CNC piston rod polishing machine
4. Automatic single head and double-heads high-speed circular saw machine
5. Automatic double-heads chamfering machine
| Main Technical Parameters | ||
| Specification | WXC80C | |
| Before Peeling Required |
Diameter Range(mm) | Φ20~Φ80 |
| Length(mm) | ≥2200 | |
| Yield Strength σb (Mpa) | ≤1100 | |
| Surface Hardness | ≤HB320 | |
| Original Curvature (mm/m) | ≤1.50 | |
| Diameter Tolerance | According to GB 702-2004 second group | |
| Roundness(mm) | ≤50% of the diameter tolerance | |
| Surface Roughness(Ra) | ≤25~50μm | |
| After Peeling | Diameter Range(mm) | Φ24~Φ77.5 |
| Diameter Cutting Depth (mm) | 0.5~2.5 | |
| Diameter Tolerance | ≤IT9 | |
| Surface Roughness(Ra) | ≤6.3μm | |
| Roundness(mm) | ≤0.03 | |
| Feeding Speed(m/min) | 1.0~10.0 | |
| Cutter Head Rotational Speed(rpm) | 430~1200 | |
| Main Machine Motor Power(kw) | 55 | |
| Main Machine Outline Dimensions (m) | 3.0 X 3.5 X 2.4 | |
| Main Machine Weight (t) | 8 | |
| Total Capacity(kw) | 75 | |
More information, feel free to contact me by follow:
Lily Wan
