Yantai Haige Machine Tools Co.,Ltd
----Professional Manufacturer of Centerless Lathe &Straightening Machine
Yantai Haige Machine Tools Co.,Ltd. was built in 1997,which is mainly producing series WXC Centerless Lathe(Bar Peeling Machine),Series JY Bar Straightening Machine,Abrasive Belt Grinder (Belt Sander Polishing Machine) and
auxiliary machine,etc.
We regard Customer’s Satisfaction as our unremitting pursuit.
Based on more than ten years manufacturer and design experience,our machine have been exported to Russia,Vietnam,India,
Korea and other countries and regions.
Series JY Straightening Machine is mainly used for precision straightening and calendering for the bar after peeling or
grinding and rough pre-straightening for the black bar.
Series JY two-rolls Straightening Machine includes two-beams and four-columns structure,prestressed structure and frame structure.
The Feature of Bar Straightener
1.high feeding straightening speed,due to calendering and straightening at the same time,so the working speed can reach
10~30m/min
2.Straightening and calendering at the same time
High precision,straightness can reach 0.15mm/m to 0.4mm/m,surface roughness Ra≤0.8μm.
Main Parts
Series JY straightening machine is mainly used forprecision straightening for the metal bar after peeling or grinding and
pre-straightening for the metal bar.
The machine adopted special curve between upper concave and the lower convex two straightening rolls to realize
calendering and straightening at the same time,which greatly improved the working efficiency.
Series JY two-rolls Straightening Machine consists of two-beams and four-columns structure,prestressed structure and frame structure.
The most vital part of a straightener is the two
straightening rollers, which designed by our qualified engineers.The upper roller is concave and the lower one is convex,
which formed a special curve to press strongly onto the materials to realize straightening,as well as calendering.
