Bar Peeling and Straightening and Polishing Machines
bright bar production line
Yantai Haige Machine Tools Co., Ltd is a professional manufacturer of cylinder processing equipment and round steel bar peeling and straightening machine and automatic production line.
Including as follows:
1. Internal cylinder tube CNC Skiving roller burnishing machine
2. Piston rod polishing machine
3. Round steel bar peeling and straightening machine
4. Automatic double-heads cutting machine
5. Automtatic Production Line
Processing Equipment and Scene
Field of Application
Field of Mechanical manufacturing:
such as mechanical processing, bearing manufacturing, oil machinery, automobile and engineering machinery parts manufacturing, metallurgy machinery and many other fields.
The field of material processing:
The products are suitable for processing all kinds of materials of round bars, such as structural steel, alloy steel, spring steel, bearing steel, tool steel and other ferrous metal materials; copper alloy, aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials.
Round steel bar automatic production line
1. 1 set prestraightening machine + 1 set peeling machine + 1 set precision straightening machine(see the above left-hand picture)
2. 2 sets peeling machine + 1 set precision straightening machine (see the above right-hand picture)
3. 1 set peeling machine + 1 set precision straightening(see the above the picture)
Cylinder Processing Equipment
CNC skiving roller burnishing machine
1. it can process inner diameters from Ø40 to Ø250 and the lengths of 1.5m, 2m, 3m, 4m, 6m, 9m, and 10m
2. Processing speed is nearly 20 times that of honing.
3. Processing precision can reach level IT8, and surface roughness can reach Ra0.05-0.4μm.
CNC piston rod polishing machine
it mainly applied to polish before and after the plating of piston rods by pass-type dyr polishing.
1. 6 sets polishing heahs, including the first 4 sets are multi-leaf wheels, the fifth set is linen wheel and the sixth set is cotton wheel.
2. SIEMENS Brand: color touch screen, frequency converter, and PLC, etc.
3. automatic loader and unloader
4. high precision, roughness Ra0.2~0.85 μm
