1.Product overview
The machine adopts the RICOH GEN4/5 of high-speed print head. It contains 384/1280 nozzles,which is four time of the past numbers of
2.Features
1.Create ultra-high quality, piezo inkjet method
Inkjet on a high-definition control for maximum resolution of 1440dpi to show pictures of the
most meticulous detail. Even six pounds of small text, smooth and sharp edges can print out.
2.Used internationally renowned brands UV-LED curing light
Used internationally renowned brands UV-LED curing light, quick drying,No distortion, no cracking,
long service life, Higher cure efficiency, more stable quality.
3.A barrel of ink ink detection alarm system
This system can be flashing lights and sound to alert the user to replace the expiring ink.
4.Suction platform wind-conditioning systems
Suction platform wind stepless adjustable size, to ensure that all material in the best condition
attached to the surface of the platform.
5.Negative pressure system
Negative pressure ink supply, to solve the long-format continuous printing without ink off.
6.Nozzle height adjustment
Depending on the print material, can very easily adjust the height of the nozzle.
7.Negative back-up power systems
When the machine power off, you can still maintain a negative pressure system to work properly,
so that the ink stays in the print out of state without waste, but also to quickly enter the working
state calls.
8.Beam aluminum beam, X to import two rails 20
Print higher precision, the car run more smoothly.
Model |
POWER 4 |
Printhead |
RICOH GEN4/GEN5 |
Resolution |
600DPI,900DPI,1200DPI,1800DPI |
Color |
CMYK,LC,LM,White or Varnish |
Media printing width |
3.2m(126inch) |
Drying system |
LED-UV curing lamp |
Media handing |
Roll to Roll |
Ink |
LED-UV Curing Ink |
Outdoor life |
At least 3 years outdoor/ 10 years indoor |
Ink Capacity |
2.5L drums, automatic ink control, non-stop and ink |
Ink supply system |
Auto Negative ink supply |
Media |
soft film, flex banner, wallpaper, car sticker, cloth |
Control System |
Windows 2000 worksation/ Windows XP/ Vista/Window7 32bit RAM>=6G |
Printing Speed |
Up to 35sqm/h |
RIP Software |
Photoprint/ ColorGATE |
Image format |
Tiff, JPEG, EPS |
Power Supply |
3.2KW; AC,50HZ/60HZ; 220V(+-10%)>15A |
Minimum Work Area |
7.6 x 2.1 x 2.60(m) |
Operation environment |
Temperature: 18-26℃ |
Dimension(L*W*H) |
5800*800*1650mm |
| Package Dimension(L*W*H) | 5270*950*1800mm |
| Net weight&Gross weight | 750kg&900kg |
Safety Certification |
CE Certification |
Suitable for various materials, such as car sticker, camp tent, marking flag, indoor
and outdoor lighting cloth, leather, cloth, decorative painting, fabrics, thin film,
wallpaper,etc
