Specifications
Pipe Handling Crane:1.We can supply various cranes
2.Awarded by CCS.ABS.LRS.BV.GL.DNV.NK.API. etc
3.ISO 9001:2000 system
Pipe Handling Crane:
Electric Hydraulic Pipe Handling Crane
This series of electric hydraulic pipe handling crane can be used for all kinds of oil tankers; chemical product carriers etc. and meet the ex-proof requirements for the danger zone and the requirements of OCIMF. Other cranes (e.g. oil-transferring crane etc.) can be designed and manufactured as per Users’ requirements. Electric Hydraulic Hose Handling Cranes are designed to meet heavy demand for multiple marine purposes. Standard model or special custom built design of requested. Capacity range from 10-500TM. SWL up to 20T and jib length up to 30 meters.
Electric Hydraulic Hose Handling Cranes can be delivered with integrated power package or connected to the exsiting hydraulic system. They also can be delivered with electric motor of an explosion proof type.
Operation:
Complete self-contained hydraulic power unit in crane house.
Control stand on the crane house (No cabin).
Main Control station: 3 levers (hoisting – slewing - luffing) simultaneous operation. (Reducing Condition).
Stepless speed control (0 ~ max)
Universal Joint (Cardan shaft, Pedestal inside- easy installation).
Basic specification for enquiry:
ing load
Max.outreach
Min.outreach
Hoisting height
Hoisting speed
Luffing time
Classification society
Electric Hydraulic Pipe Handling Crane Specifications:
Type |
SWL |
Working radius |
Lifting speed |
Luffing time |
Rotating velocity |
GHMDC HP001 |
1T |
7m |
20 m/min |
45s |
1 r/min |
GHMDCHP002 |
1T |
12m |
15m/min |
50s |
1r/min |
GHMDC HP003 |
1T |
16m |
15m/min |
45s |
1r/min |
GHMDC HP004 |
2T |
7m |
15m/min |
45s |
1r/min |
GHMDC HP005 |
2T |
10m |
15m/min |
50s |
1r/min |
GHMDC HP006 |
2T |
12m |
15m/min |
50s |
1r/min |
GHMDC HP007 |
2T |
14m |
15m/min |
50s |
1r/min |
GHMDC HP008 |
2T |
16m |
15m/min |
50s |
1r/min |
GHMDC HP009 |
2T |
20m |
15m/min |
60s |
1r/min |
GHMDC HP010 |
3T |
8m |
15m/min |
60s |
1r/min |
GHMDC HP011 |
3T |
13m |
15m/min |
60s |
1r/min |
GHMDC HP012 |
4T |
6m |
15m/min |
50s |
1r/min |
GHMDC HP013 |
4T |
10m |
15m/min |
60s |
1r/min |
GHMDC HP014 |
4T |
16m |
15m/min |
90s |
1r/min |
GHMDC HP015 |
4T |
22m |
15m/min |
90s |
1r/min |
GHMDC HP016 |
5T |
7m |
15m/min |
60s |
1r/min |
GHMDC HP017 |
5T |
10m |
15m/min |
80s |
1r/min |
GHMDC HP018 |
5T |
16m |
15m/min |
90s |
1r/min |
GHMDC HP019 |
5T |
20m |
15m/min |
90s |
1r/min |
GHMDCHP020 |
10T |
16m |
15m/min |
80s |
1r/min |
Hydraulic pipe handling Crane
Hydraulic Slewing Crane
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
