Help CenterBoost Module 12v19v Boost 12V Liter 24v5a12v Car Boost Module 150W High Power
Related Products
-
5 in 1 Ultrasonic Module / Temperature Compensated /51 System Board + Ultrasonic Distance Measurement ModuleUS$ 1 - 100MOQ: 1 Piece -
VGA Compression Chip AD603AQ DIP-8 High Gain Precision Ceramic LineUS$ 1 - 100MOQ: 1 Piece
-
5A DC-DC Solar Controller MPPT Decompression Module With Digital Display Constant CurrentUS$ 1 - 100MOQ: 1 Piece
-
Computer Cable Crimping Pliers FC Crimping Pliers for Pressing the FC Terminal LineUS$ 1 - 100MOQ: 1 Piece
-
2.8 Inch TFT LCD Screen With Touch Screen Module STM 51 MCU Support SD CarUS$ 1 - 100MOQ: 1 Piece
2014 Sony, 150W booster module, 12-32V wide input voltage, 12-46V adjustable output voltage, low input and output voltage difference.
Digital tube can display the input and output voltage, button switch display,
Appearance size: long wide high =8.5cm 5.8cm 3.3cm
Product specifications:
Module name:150W boost module
Module property:Non isolated boost module (BOOST)
Input voltage:12-32V input (for wide input voltage range applications)
Input current:16A (MA) more than 8A please strengthen the heat
Static working current:15mA (12V liter 20V, the output voltage, the more Gao Jing current will increase)
Output voltage: 12-46V continuous adjustable
Output current:8MA A more than 4A please strengthen the heat (and input, output voltage, the greater the difference between the output voltage of the smaller)
Output power:Natural heat dissipation 90W, enhanced heat dissipation 150W
Operating temperature: -40~+85 degrees (if the ambient temperature is too high, please strengthen the heat)
Operating frequency:150KHz
Conversion efficiency:Maimum 95% (efficiency with input, output voltage, current, differential pressure)
Short circuit protection:There (input 15A fuse)
Input reverse protection: have
Connection mode:TerminalFreeWelding output,Matched case for welding output.(V-IN for the input, V-OUT for the output
Application range:
1, DIY a regulated power supply, 12V input can be, the output can be adjusted 12-46V.
2, for your electronic equipment, power supply, you can follow the system voltage to set the output value.
3,As a car powered power supply, for your laptop, PDA or a variety of digital products. Can be selected high-grade thickening grinding sand aluminum alloy shell, direct PK off the market common car power or inverter, is like the metal teture of your best choice.
4, DIY a high power mobile notebook power supply: with large capacity 12V lithium batteries, let your books to go to where you can light.
