model:QS-4805CBAN-90W Power module

rulerInch: 72 (long) *42 (wide) *23 (high) mm (ecluding the hole, with the installation hole length of 90 mm)

Module parameters

Module propertyNon isolated buck module (Buck)

Rectifier mode:wrongSynchronous rectification

Input voltage:4.5-60V (Foot 61V measured 60V can work)

Output voltage:(1) continuous adjustable(1.25-30)

(2) fied output (1.25-30 between any choice), (only for the batch single).

Default shipping for adjustable output.

Output current:Ma 3A.Can 3A 30V full load 90W

Conversion efficiency:highest92% (the smaller the pressure difference, the higher the efficiency)specificSee the back of the test chart

Switching frequency:50KHz

Low dropout:2V

Working temperature:Industrial grade (-40 C to +85 C) (within the output power of 20W)

Full load temperature rise:40 C

Load regulation rate:+ 0.5%

Voltage regulation rate:.0.5%

Output ripple:

Input 5V output 3A 48V ripple less than 10mV

20M bandwidth

Dynamic response speed:5% 200uS

Short circuit protection:Limit current, self restore (output voltage below 20V)

Output over voltage protection:AdjustableThe output of the output is not with overvoltage protection function, the fied output can be selected output with over-voltage protection function.



Input back protection:yes.

Installation method:Screw fiation (3 mm in diameter), 2 fied holes, 2 fied holes between 82 mm

Connection mode:You can plug terminals, wire, welding is not required



Shell:Aluminum shell, encapsulation technology, can work in harsh conditions

Weight:120g
