Specifications
Leveling And Cut To Length Line1.Automatic sheet feed
2.Smoothness by adjusting screw
3.CNC uncoiler
4.ISO9001:2008
T44QK-16-2000 CNC Hydraulic Leveling And Cut To Length Line
1. T44QK-16-2000 CNC Hydraulic Leveling And Cut To Length Line
This equipment is used to expand the steel coil, leveling and automatic production line which cut into desired size. Artificial head fed into the plate leveler .after the rest of actions, the operator will operate touch screen to enter speed, cutting length, cutting quantity.
2. Scope Of Device:
(1) |
coil materials:
|
cold-rolled plate |
(2) |
sheet thickness: |
4~16mm |
(3) |
sheet width: |
≤1600mm |
(4) |
coil diameter: |
φ610mm,φ760mm |
(5) |
coil out diameter: |
≤φ2000mm |
(6) |
coil weight: |
≤30 tons |
3. Unit parameter
(1) |
finished speed: |
≤10pcs/min(count as 2m/piece) |
(2) |
cutting length tolerance: |
≤±0.5mm |
(3) |
diagonal tolerance: |
≤±1.0mm |
(4) |
unit power |
7.5kw |
(5) |
unit area: |
(l×w)about 12m×4.8m |
(6) |
unit running direction: |
(face to console)from left to right |
4. Part Of Production Line:
1.simple decoiler 5.cut to length
2.transitional roller 6.cross shear
3.side guide device llecting table
4.pinch and nine roller leveler 8.electrical system
T44QK-16-2000 CNC Hydraulic Leveling And Cut To Length Line :
T44QK-16-2000 CNC Hydraulic Leveling And Cut To Length Line :
Specification details please visit our website: /
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices !
