Home > Products > Small Diesel Generator > Generating Set Diesel
Generating Set Diesel
Negotiable
/ Piece
10 Pieces(Min. Order)
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | KAIAO | |
| Model Number | KDE5500E | Output Type | AC Single Phase | |
| Speed | 3000 3600 | Frequency | 50 60 | |
| Rated Power | 4.5/5.2 | Rated Voltage | 115/230 120/240 | |
| Rated Current | 36.5/18.3 40/20 |
Product Description
| KDE5500X/E/X3/E3 | ||||
| Model | KDE5500X/E | KDE5500X3/E3 | ||
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Rate Power(KVA) | 4.2 | 4.8 | 5.3 | 6 |
| Max.power(KVA) | 4.5 | 5.2 | 6 | 6.5 |
| Voltage(V) | 115/230 | 120/240 | 230/400 | 240/416 |
| Current(A) | 36.5/18.3 | 40/20 | 7.7 | 8.3 |
| Engine speed(r/min) | 3000 | 3600 | 3000 | 3600 |
| Phase | Single | 3-phase | ||
| Excitation system | Self-excited constant voltage | |||
| Noise level (7m) | 77 | |||
| Fuel tank capacity (L) | 12.5 | |||
| Structure | open-frame | |||
| Panel | Oridinary | |||
| Output socket | Two | One single-phase ,and one3-phase | ||
| Output terminal post | No | |||
| DC12V output | Terminal post | |||
| Net weight(kg) | Type X:95 Type Y:100 | |||
| Dimension(L*W*H) | 760*515*710 | |||
| Engine Model | KA186F | |||
| Engine Type | Single-cylinder,vertical,four-stroke,air-cooled,direct injection | |||
| Bore*stroke (mm) | 86*70 | |||
| Displacement (L) | 0.406 | |||
| Power (KW) | 5.7/3000 | 6.3/3600 | 5.7/3000 | 6.3/3600 |
| Fuel consumption rate (g. KW/h) | 271.5 | 280 | 271.5 | 280 |
| Compression ratio | 19 | |||
| Lubrication system | Spring | |||
| Engine starting system | Type X:Recoil starter Type E: Electric starter | |||
| Diesel oil model | Summer:0#,Winter:-10# | |||
| Lube oil model | SAE10W-30(above CD grade) | |||
| Lube oil capacity (L) | 1.65 | |||
| Battery capacity(V-AH) | 12V-36Ah | |||
