New Condition Cement Mill For Cement Plant
Cement mill introduction
Cement mill has many advantages such as, strong adaptability, continuous production, large crushing ratio, easy to adjust the size of the products.
Cement mill is mainly used in grinding raw materials and final products in cement plant. It is also suitable for grinding various ores and other materials in the metallurgy, mine, chemical, construction and other industries. Besides, it has two forms of milling, one is an open form, and the other is a recycle close form equipped with powder concentrator. It is widely applied in many industries and has convenient operation.
Finished cement mill in our factory
Feature of cement mill
1) Efficient tool for grinding many materials into fine powder.
2) For Mineral grinding
3) Also used in building material, and chemical industry.
4) Dry type and wet type ball mill.
5) Manganese alloy liners, ceramic liner, rubber liner.
6) The longer the ball mill runs, the finer the powder will be.
7) With excellent motor and reducer supplier
8) For home private mineral processing test, also for laboratory testing
the gear of the ball mill
Discharge port of grinding mill
Ball Mill Grinding Cermic Ball:
Cement mill technical parameters
Model |
Rotation speed (r/min) |
Grinding media loading(t) |
Feed size (mm) |
Discharge size (mm) |
Capacity (t/h) |
Power (kw) |
Weight (t) |
Φ900*2100 |
38 |
1.5 |
≤15 |
0.075-0.89 |
0.5-2 |
15 |
3.9 |
Φ900*2400 |
38 |
1.8 |
≤15 |
0.075-0.89 |
0.7-2.8 |
18.5 |
4.5 |
Φ900*3000 |
38 |
2.51 |
≤15 |
0.075-0.89 |
0.8-3.5 |
22 |
5.0 |
Φ1200*2400 |
32 |
3.8 |
≤20 |
0.074-0.4 |
0.9-4.8 |
30 |
9.2 |
Φ1200*2800 |
32 |
4.0 |
≤20 |
0.074-0.4 |
1.0-5.0 |
30 |
9.5 |
Φ1200*3000 |
32 |
4.5 |
≤20 |
0.074-0.4 |
1.2-5.6 |
37 |
11.5 |
Φ1200*4500 |
30 |
5.5 |
≤20 |
0.074-0.4 |
1.5-6.0 |
55 |
13.6 |
Φ1500*3000 |
27 |
7.0 |
≤25 |
0.074-0.4 |
2.5-6.5 |
75 |
15.0 |
Φ1500*3500 |
27 |
8.5 |
≤25 |
0.074-0.4 |
3.0-8.2 |
75 |
15.6 |
Φ1500*4500 |
27 |
11 |
≤25 |
0.074-0.4 |
4-10 |
95 |
21 |
Φ1500*5700 |
27 |
12 |
≤25 |
0.074-0.4 |
4-13 |
110 |
23.5 |
Φ1830*3000 |
24 |
12 |
≤25 |
0.074-0.4 |
5-15 |
130 |
31 |
Φ1830*3600 |
24 |
13 |
≤25 |
0.074-0.4 |
5-16 |
130 |
32 |
Φ1830*4500 |
24 |
14 |
≤25 |
0.074-0.4 |
5-18 |
155 |
33.5 |
Φ1830*7000 |
24 |
21 |
≤25 |
0.074-0.4 |
6-20 |
210 |
36 |
Φ2100*3000 |
24 |
18 |
≤25 |
0.074-0.4 |
7-26 |
210 |
38 |
Φ2100*3600 |
24 |
21 |
≤25 |
0.074-0.4 |
7-35 |
215 |
39.5 |
Φ2100*4500 |
24 |
26 |
≤25 |
0.074-0.4 |
8-42 |
245 |
43.5 |
Φ2200*3000 |
21 |
28 |
≤25 |
0.074-0.4 |
8-43 |
245 |
46 |
Φ2200*4800 |
21 |
35 |
≤25 |
0.074-0.4 |
9-45 |
285 |
48 |
Φ2400*3000 |
21 |
23 |
≤25 |
0.074-0.4 |
8-60 |
285 |
55 |
Φ2700*4500 |
21 |
48 |
≤25 |
0.074-0.4 |
12-83 |
475 |
79 |
Cement mill Working site in cement plant
1.The continents such as South America, Middle East, Africa, Oceania and Europe Etc, we will send machinery to you by ship.
2.For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan etc., we can ship construction machinery by road or railway.
3.For light weight of the goods or components, we can also send it by international courier service, such as DHL, TNT, UPS, or FEDEX.
the delivery of the ball mill
Zhengzhou Jinma Mining Machinery Co., Ltd. was established in 1976 subordinated to China Machinery Engineering & Construction Corporation, the company specializes in manufacturing large and medium-size crushers, sand making machine, ball mill, magnetic separator, flotation machine, mineral processing equipments, and related machines.
Located in No. 8 Dianchang Road, Zhengzhou,Henan Province and covers an area of 70000 square meters.
The products are exported to over 50 countries like Chile, Peru, Costa Rica, USA, Vietman,Indonesia,Malaysia,India,Philippines,Pakistan,Iran,Russia, Kazakhstan, Azerbaijan, Turkey, North Korea, South Africa, Tanzania, Ghana, etc.
With the goal of ”The excellence, the better ”and “satisfaction from customers” as the eternal pursuit, we sincerely welcome clients from all over the world to come for a visit and establish a long-term relations of cooperation.
here is the certificate of our factory
1.How long is the delivery time of your equipment?
The delivery time is within 30 working days. But when the project is very big and the customers have special requirement on the equipment, the delivery could be extended.
2.How long is the equipment warranty period?
Our equipment warranty period is 1 year. Wearing parts and problem coursed by worker’s wrong operation are not included.
3.Can you provide wearing parts?
We have two casting factories that specialize in produce wearing parts for our clients. If your equipment are not manufactured by our company, please provide us the wearing parts drawing.
4.Can you give me a solution and quotation?
Of course, to provide accurate solution and quotation, please give us background information, including, raw material, the capacity, max. input size, the output size, the usage of final products, etc.
