Home > Electrical & Electronics > Power Supply & Distribution > UPS > Long Back up Time Ups 1kva External Battery Type
Long Back up Time Ups 1kva External Battery Type
US$ 104.00 - 104.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
C1KS
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen hongkong guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
True Online Double Conversion and IGBT Technology Ups Power System 2ksUS$ 104.00 - 104.00MOQ: 1 Piece -
1KVA 2KVA 3KVA Without Battery Ups Power SystemUS$ 104.00 - 104.00MOQ: 1 Piece
-
Online Rackmount Ups Power 1kva to 3kvaUS$ 149.00 - 149.00MOQ: 1 Piece
-
230V Rackmount Ups 1000va With BatteryUS$ 149.00 - 149.00MOQ: 1 Piece
-
High Quality Rackmount Ups 2kvaUS$ 149.00 - 149.00MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
OEM
Model Number
C1KS
Phase
Single Phase
Protection
Overvoltage
Weight
4.2kg
Output Voltage
110V/120V/220V/230V
Type
On-line
Application
Security / Monitoring / Alarm
36VDC ONLINE UPS long time back up
Double conversion and IGBT technology
Advanced battery management
Crest factor1:3
Wide input range
High frequency online UPS
Key Features
True on-line double conversion technology with advanced microprocessor control
Wide input voltage range
Zero transfer time
Protection against all type of power problems
Self test while start of the UPS
Site wiring fault warning
On-battery power-on function
Smart RS232 communication interface
Intelligent slot available
Sealed lead-acid, maintenance free battery
| MODEL | 1K (S) | 2K (S) | 3K (S) | |
| PHASE | Single phase with ground | |||
| CAPACITY | 1000 VA / 800 W | 2000 VA / 1600 W | 3000 VA / 2400 W | |
| INPUT | ||||
| Nominal Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | |||
| Input Voltage Range | 55-145 VAC or 110-300 VAC | |||
| Frequency Range | 40Hz ~ 70 Hz | |||
| Power Factor | 0.99 @ Nominal Voltage (100% load) | |||
| OUTPUT | ||||
| Output Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | |||
| Voltage Regulation | ± 1% | |||
| Frequency Range (Synchronized Range) | 47~ 53 Hz or 57 ~ 63 Hz | |||
| Frequency Range (Batt. Mode) | 50 Hz or 60Hz ± 0.1 Hz | |||
| Current Crest Ratio | 3:1 | |||
| Harmonic Distortion | 3 % THD (Linear Load) 6 % THD (Non-linear Load) |
|||
| Transfer Time | AC to DC | Zero | ||
| Inverter to Bypass | 4 ms (Typical) | |||
| Waveform (Batt. Mode) | Pure Sinewave | |||
| EFFICIENCY | ||||
| To AC Mode | 88% | 89% | 90% | |
| To Battery Mode | 83% | 87% | 88% | |
| BATTERY | ||||
| Standard Model | Battery Type | 12 V / 7 AH | 12 V / 7AH | 12 V / 7 AH |
| Numbers | 2 | 6 | 6 | |
| Typical Recharge Time | 4 hours recover to 90% capacity | |||
| Charging Current (max.) | 1.0 A | |||
| Charging Voltage | 27.4VDC ± 1% | 82.1 VDC ±1% | 82.1 VDC ±1% | |
| Long-run Model* | Battery Type | Depending on the capacity of external batteries | ||
| Numbers | 3 | 6 | 8 | |
| Charging Current (max.) | 1.0A/2.0A/4.0A/6.0 A | |||
| Charging Voltage | 41.0VDC ± 1% | 82.1 VDC ±1% | 109.4VDC ±1% | |
| INDICATORS | ||||
| LCD | Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators | |||
| ALARM | ||||
| Battery Mode | Sounding every 4 seconds | |||
| Low Battery | Sounding every second | |||
| Overload | Sounding twice every second | |||
| Fault | Continously sounding | |||
| PHYSICAL | ||||
| Standard Model | Dimension, D x W x H (mm) | 397 X 145 X 220 | 419X190X318 | |
| Net Weight (kgs) | 13 | 26 | 28 | |
| Long-run Model* | Dimension, D x W x H (mm) | 282 x 145 x 220 | 397 X 145 X 220 | |
| Net Weight (kgs) | 4.6 | 6.8 | 7.4 | |
| ENVIRONMENT | ||||
| Humidity | 20-90 % RH @ 0- 40°C (non-condensing) | |||
| Noise Level | Less than 50dBA @ 1 Meter | |||
| MANAGEMENT | ||||
| Smart RS-232/USB | Supports Windows 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC | |||
| Optional SNMP | Power management from SNMP manager and web browser |
|||
