LX200Y 50w yag marking laser machine
Paramentars
Name: |
LX200Y 50w yag marking laser machine |
Laser Output Power |
50W / 6ow |
Beam quality |
m2<6 |
Standard Marking Scope |
110 mm×110mm |
Optional Marking Scope |
100mm×100mm/150mm×150mm |
repeat frequency: |
≤50KHz |
Marking Depth |
0.3mm (depend on the materials ) |
Marking Speed |
≤7000mm/second |
Repeated Accuracy |
±0.001mm |
Laser Wavelength |
1064μm |
Minimum Line Width |
0.02mm |
Min character |
0.25mm |
Power Supply |
220V/50Hz/ 15A |
consumption power |
≤2.5KW |
cooling mode |
Internal circulating water cooling |
accessories |
3d workbench , 2P chiller |
Operating temperature |
15 ºC -35 ºC |
Features and Advantages
² LX200Y series of semiconductor laser marking machine can easily realize precision marking, mark all kinds of materials and a variety of non-metallic materials
² Using the international most advanced imported encapsulating semiconductor array, and equipped with high-speed galvanometer, Q switch and laser rod, high scanning speed and high precision
² Independent control cold water circulation system, low noise, accurate precision temperature control. The whole machine performance is stable, can entirely suitable for the needs of the industrial site 24 hours of continuous work
² Optical system adopts fully sealed structure, with the functions of graphical preview and focus indicator, marking accurate processing to avoid waste
² Feature-rich software design, adopts a flexible and fast menu-style friendly work interface, easy to use, support windows 7/xp/2000 system, supports for multiple language interface. Free to design the required processing graphic pattern. Supports true type fonts, single font(JSF) , bitmap fonts (MDF) , Y one-dimensional and two-dimensional bar code.
² Compatible with common image formats (BMP, JPG, GIF, TGA, PNG, TIF, etc) , compatible with commonly used vector graphics (AI, DXF, DST, PLT, etc) ; the commonly used image processing functions (gray level transformation, black and white figure transformation, network processing, etc.) ;can be a level 256 grayscale image processing
² A variety of control object, the user can freely control system interaction with external devices
FAQ
1. About us?
We are one of the true manufacturer, big factory, located at Jinan. About 5 minutes to Jinan Air port.
2. About price and quality?
We can not say we are the best supplier, but we are honesty for our quality and price.
If you want to get cheapest machine, sorry we do not support you to buy. Good quality
is our first rule. We produce machines as 5S management rules, and ISO standard.
3. Which machine you can get from us expect laser machine?
We produce laser engraving machine, laser cutting machine, laser marking machine, and also
sale .cnc woodworking machine, cnc stone engraving and cutting machine, cutter plotters. We will keep you with a best service.
We are looking for agents from all over the world.
If u have any question,friendly contact with me .
I will devote to answer your questions.
n Skype:liangxun.jn
