wood cnc machine cnc router 13251.For woodworking
2.DSP off-line control system
3.LCD display,USB interface
4.CE
wood cnc machine cnc router 1325
Technical Paraments :
Steel structure, square orbit, ball screw for z axis, gear-wheel for x axis and y axis, DSP system, Type3 Software, 4.5KW China domestic made water cooling spindle, vacuum table and dust collector system with 6 zones separately control, dust cover, ,10cutters( φ6, φ12.7), 2 collets
The model |
LX1325 |
XY working area |
1300*2500 mm(4.3feet*8.3feet) |
Z working area |
200mm or depend on customer |
Table size |
1680*3100mm |
Whole machine size: |
3250mm*2000mm*1.8mm |
Max. speed |
40m/min |
Max. working speed |
25m/min |
Working precision |
0.04mm |
Repositioning accuracy |
0.025mm |
Holding mode |
By suction with 6 zones separately control system |
Engraving Command |
Gcode*u00* mmg*plt |
Surroundings |
Windows98/2000/xp |
Power(not include the spindle) |
1840w |
power |
AC380/50HZ or 60HZ |
Spindle power |
4.5kw water cooling spindle / Italy HSD air cooling spindle(option) |
Main axle rotating speed |
0-24000rpm/min |
Work mode |
stepper / servo motor(option) |
XYZ Structure |
Steel structure, square orbit, ball screw for z axle, gear-wheel for x axle and y axle |
Engraving software |
Artengraver / Ucancam V8 / type 3 |
Control software |
DSP / Ncstudiao |
Knife pressure |
0.7Kpa |
Gross power |
20KW |
The machine adopts the DUST COLLECTOR SYSTEM ; DUST COVER ; AUTO OILLING SYSTEM | |
